VQT3R83

Control reference guide

1 Standby/on switch (Í/I)

Press to switch the unit from on to standby

mode or vice versa. In standby mode, the unit

is still consuming a small amount of power.

2 Remote control signal sensor (> 9)

3 Adjust the volume of the speakers

4 Select the input source

TV # HDMI 1 # HDMI 2

^----------------------------------}

5 Input selector indicators

A TV indicator

Lights green when the TV is the audio

source

B HDMI IN 1, HDMI IN 2 indicator

When the device connected to the HDMI IN

1 terminal or the HDMI IN 2 terminal is the

audio source (B lights in amber)

6 Audio format indicators

C Dolby Digital indicator

Lights when Dolby Digital is the current

audio format

D DTS indicator

Lights when DTS is the current audio

format

E PCM indicator

Lights when PCM (2ch, Multi-channel) is

the current audio format

7 Speaker terminals (> 21)

8 HDMI OUT terminal (ARC compatible) (> 18)

9 HDMI IN 1 terminal (> 20)

10 HDMI IN 2 terminal (> 20)

11 OPTICAL DIGITAL AUDIO IN terminal (> 19)

12 AC IN terminal (> 21)

13 AC Voltage selector (> 21)

§ The indicators will also blink in various conditions (> 28)

Active subwoofer

VOLT ADJ

110-127V• •220-240V

314

8 9 10 11

(For South

East Asia and

the Middle

East)

Active subwoofer

(front)

Active subwoofer

(rear)

SC-HTB15EGEBGNGS_VQT3R83.book Page 6 Tuesday, June 28, 2011 2:34 PM
