Precautions

VQT3R83

Caution for AC Mains Lead

(For the United Kingdom and Ireland)

For your safety, please read the following text

carefully.

This appliance is supplied with a moulded three pin

mains plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure

that the replacement fuse has a rating of 5-ampere

and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark Ï or the BSI mark Ì on

the body of the fuse.

If the plug contains a removable fuse cover you

must ensure that it is refitted when the fuse is

replaced.

If you lose the fuse cover the plug must not be used

until a replacement cover is obtained.

A replacement fuse cover can be purchased from

your local dealer.

If a new plug is to be fitted please observe the

wiring code as stated below.

If in any doubt please consult a qualified electrician.

IMPORTANT

The wires in this mains lead are coloured in

accordance with the following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the

coloured markings identifying the terminals in your

plug, proceed as follows:

The wire which is coloured Blue must be connected

to the terminal which is marked with the letter N or

coloured Black or Blue.

The wire which is coloured Brown must be

connected to the terminal which is marked with the

letter L or coloured Brown or Red.

WARNING: DO NOT CONNECT EITHER WIRE

TO THE EARTH TERMINAL WHICH IS MARKED

WITH THE LETTER E, BY THE EARTH SYMBOL

OR COLOURED GREEN OR GREEN/

YELLOW.

THIS PLUG IS NOT WATERPROOF—KEEP

DRY.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type

of AC mains plug (figures A and B). Confirm the AC

mains plug fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

2. Replace the fuse and close or attach the fuse cover.

CAUTION!

IF THE FITTED MOULDED PLUG IS

UNSUITABLE FOR THE SOCKET OUTLET IN

YOUR HOME THEN THE FUSE SHOULD BE

REMOVED AND THE PLUG CUT OFF AND

DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE

ELECTRICAL SHOCK IF THE CUT OFF PLUG

IS INSERTED INTO ANY 13-AMPERE SOCKET.

Figure A Figure B

Fuse cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)
