Manual

Operating Instructions

Caution for AC Mains Lead

For your safety, please read the following text

carefully.

This appliance is supplied with a moulded three

pin mains plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please

ensure that the replacement fuse has a rating of

5-ampere and that it is approved by ASTA or

BSI to BS1362.

Check for the ASTA mark Ï or the BSI mark Ì

on the body of the fuse.

If the plug contains a removable fuse cover you

must ensure that it is refitted when the fuse is

replaced.

If you lose the fuse cover the plug must not be

used until a replacement cover is obtained.

A replacement fuse cover can be purchased

from your local dealer.

If a new plug is to be fitted please observe the

wiring code as stated below.

If in any doubt please consult a qualified

electrician.

IMPORTANT

The wires in this mains lead are coloured in

accordance with the following code:

Blue: Neutral, Brown: Live.

As these colours may not correspond with the

coloured markings identifying the terminals in

your plug, proceed as follows:

The wire which is coloured Blue must be

connected to the terminal which is marked with

the letter N or coloured Black or Blue.

The wire which is coloured Brown must be

connected to the terminal which is marked with

the letter L or coloured Brown or Red.

WARNING: DO NOT CONNECT EITHER

WIRE TO THE EARTH TERMINAL WHICH

IS MARKED WITH THE LETTER E, BY THE

EARTH SYMBOL

OR COLOURED

GREEN OR GREEN/YELLOW.

THIS PLUG IS NOT WATERPROOF—KEEP

DRY.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the

type of AC mains plug (figures A and B).

Confirm the AC mains plug fitted and follow the

instructions below.

Illustrations may differ from actual AC mains

plug.

1. Open the fuse cover with a screwdriver.

2. Replace the fuse and close or attach the fuse

cover.

CAUTION!

IF THE FITTED MOULDED PLUG IS

UNSUITABLE FOR THE SOCKET OUTLET

IN YOUR HOME THEN THE FUSE SHOULD

BE REMOVED AND THE PLUG CUT OFF

AND DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE

ELECTRICAL SHOCK IF THE CUT OFF

PLUG IS INSERTED INTO ANY

13-AMPERE SOCKET.

Figure A Figure B

Fuse

cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

SCHTB10EB_RQTX1166-B.book Page 3 Thursday, June 10, 2010 3:06 PM
