Manual

RQT8654

Control reference guide

AC IN

WIRELESS LINK

(28)

(29, 28)

(28)

(30, 23)

(29) (16) (30)

(28)

Turn the unit on/off (10)

Select disc’s title numbers etc./Enter numbers (15)

Basic operations for play (14, 15)

Show a disc top menu (17) or program list (18)

Frame-by-frame/Select or register menu items on the

television screen (15)

Show on-screen menu (20) or

display RDS text data ([Continental]Europe] only) (27)

Change the television’s video input mode (31)

Return to previous screen (15)

Adjust the volume of the main unit (15)

Select the source

DVD: DVD/CD (10)

TUNER/BAND: FM/AM (26)

EXT-IN: MUSIC P. (30), TV

(31), AUX (31)

Cancel (15)

Change the unit’s display (15)

See page references in parentheses.

SELECTOR (26)

DVD/CD# FM#AM# TV

#AUX #MUSIC P. #

Return to DVD/CD

[Continental]Europe] “TV” works only when the

scart cable is connected (➜ page 9).

< OPEN/CLOSE

Open/Close the disc tray (14)

∫ /

TUNE MODE /

FM MODE

Stop playing (14)/Select the tuning mode (26)

Adjust the FM reception condition (26)

1 / MEMORY

Play discs (14)/Memorize the receiving radio

stations (26)

4, 5 / X TUNING W

Skip or slow-search play (14)/

Select the radio stations (26)

Standby/on switch [Í/I]

Press to switch the unit from on to standby mode

or vice versa. In standby mode, the unit is still

consuming a small amount of power. (14)

VOLUME

Turn up/down the volume (14)

AC supply indicator [AC IN]

This indicator lights when the unit is

connected to the AC mains supply.

Phones

Connect headphones (30)

MUSIC PORT

Connect an external device (30)

Remote control signal sensor

Television operations (31)

Adjust the television volume (31)

Select preset radio stations (26)

[HT545W]

To use functions labeled with “

”:

Press and hold the button for at least 2 seconds.

Display

AC supply indicator [AC IN]

This indicator lights when the unit is

connected to the AC mains supply.

The unit is in the standby condition when the

AC power supply cord is connected.

The primary circuit is always “live” as long as

the power cord is connected to an electrical

outlet.

Lighting Ring

Lights when the wireless link is active.

[HT545W]

The illustration shows the

wireless system for SC-HT545W.

Show a disc menu (17) or play list (18)

The illustration shows SC-HT545.

8654En_p03-13.fm Page 11 Monday, April 10, 2006 5:05 PM
