RQT6713

1 AC supply indicator (AC IN)

This indicator lights when the unit is connected to the AC mains

supply.

2 Standby/on switch (

f/I)

Press to switch the unit from on to standby mode or vice versa.

In standby mode, the unit is still consuming a small amount of

power.

3 Display

4 Remote control signal sensor ................................... 5

5 Super sound EQ button (SUPER SOUND EQ) ........ 11

6 Preset EQ select button (PRESET EQ) ................... 11

7 Deck 1 cassette holder ..............................................11

8 Disc tray

9 CD tray open/close button (c, OPEN/CLOSE) ......... 8

0 Disc direct play buttons (1 ~ 5) ................................. 8

! Headphones jack (PHONES) .................................... 12

@ Deck 2 cassette holder ..............................................11

Main unit

Center console

# Tuner/band select button (TUNER/BAND) .............. 10

$ CD skip/search, tape fast-forward/rewind,

tune/preset channel select, time adjust buttons

(g/REW/3, f/FF/4) .................... 8, 9, 10, 11, 13

% Record button (a REC) ..............................................11

^ Deck select button (DECK 1/2) ................................ 11

& Display, demonstration button (-DISP/–DEMO) ...... 13

* Deck 1 open button (c, DECK 1) ............................ 11

( AUX button (AUX) ...................................................... 12

) Volume control (VOLUME DOWN, UP) .................... 13

- CD play/pause button (:/ J, CD) ............................... 8

= Stop/program clear button (L, STOP) ........... 8, 11, 12

[ Deck 2 open button (c, DECK 2) ............................ 11

] Tape play button (:, TAPE) ............................... 11, 12

Remote control

Buttons such as 2 function in exactly the same way as the

buttons on the main unit.

\ Sleep timer/auto off button

(SLEEP, –AUTO OFF) ..........................................13, 14

; Disc button (DISC) ...................................................... 9

Program button (PROGRAM) ..................................... 9

, Muting button (MUTING) ........................................... 13

SC-AK310

SC-AK110

CD display button (CD DISP) ..................................... 8

SC-AK210

CD display/RDS display button

(CD/RDS DISP) ...................................................... 8, 10

/ Dimmer button (DIMMER) .........................................13

_ Play timer/record timer button (rPLAY/REC)......... 14

+ Clock/timer button (CLOCK/TIMER) .................. 13, 14

{ Numbered buttons (

10, 1–9, 0) .......................... 9, 10

} Play mode select button (PLAY MODE) ........ 9, 10, 12

Front panel controls

DECK 2

TA PE

TUNER /

BAND

AUX

DECK 1/2

REC

STOP

REW FF

DECK 1

DISP/

DEMO

This illustration is of SC-AK310.

SLEEP

CLOCK

TIMER

REC

AUTO OFF

UTO OFF

DISC

PROGRAM

S.SOUND EQ

PRESET EQ

MUTING

REW

CLEAR

CD DISP

DIMMER

PLAY MODE

5 6

VOL

AUX

TUNER

BAND

TA PE

TAPE
