3
RQTX1147
Caution for AC Mains Lead
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug
for your safety and convenience.
A 5-ampere fuse is fi tted in this plug.
Should the fuse need to be replaced please ensure that
the replacement fuse has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark
or the BSI mark on the body of
the fuse.
If the plug contains a removable fuse cover you must ensure
that it is refi tted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUI T ABLE FOR
THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE
SHOULD BE RE MOVED AND THE PLUG CUT OFF AND
DIS POSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRI CAL
SHOCK IF THE CUT OFF PLUG IS IN SERTED INTO ANY
13-AMPERE SOCKET.
If a new plug is to be fi tted please observe the wiring code as
stated below.
If in any doubt please consult a qualifi ed electrician.
IMPORTANT
The wires in this mains lead are coloured in accor dance with
the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured
markings identifying the terminals in your plug, proceed as
follows:
The wire which is coloured Blue must be connected to the
terminal which is marked with the letter N or col oured Black or
Blue.
The wire which is coloured Brown must be connected to the
terminal which is marked with the letter L or coloured Brown or
Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE
EARTH TERMINAL WHICH IS MARKED WITH THE LETTER
E, BY THE EARTH SYMBOL
OR COLOURED GREEN OR
GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF—KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type of AC
mains plug (fi gures A and B). Confi rm the AC mains plug fi tted
and follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
Figure A Figure B
Fuse cover
2. Replace the fuse and close or attach the fuse cover.
Figure A
Fuse
(5 ampere)
Figure B
Fuse
(5 ampere)
Safety precautions
• Avoid using or placing this unit near sources of heat. Do not
leave it in an automobile exposed to direct sunlight for a long
time with the doors and windows closed as this may deform
the cabinet.
• Avoid cuts, scratches, or poor connections in the AC mains
lead, as they may result in possible fi re or electric shock
hazard. Also, excessive bending, pulling or splicing of the
lead should be avoided.
• Do not unplug the AC mains lead by pulling on the lead. To
do so may cause premature failure or shock hazard.
• Do not operate this unit in a bathroom, as a potential shock
hazard may result.
• When not in use, disconnect the AC mains lead from the
household mains socket.
Table of contents
Caution for AC Mains Lead ............................ 3
Safety precautions .........................................3
Use of batteries ............................................... 3
Power sources ................................................ 4
Overview of controls ...................................... 4
Discs ................................................................ 5
Using the FM/AM radio ................................... 5
Cassette tape – Play and record ................... 6
Using the clock and timers ............................7
Using sound effects ....................................... 7
Maintenance .................................................... 7
Troubleshooting guide ..................Back cover
Specifi cations ................................Back cover
Use of batteries
• If this unit is not used for a long period of time or is used
only from an AC power source, remove all the batteries
to prevent potential damage due to possible battery
leakage.
• Do not mix old and new batteries.
• Do not use different types of batteries at the same time.
• Do not take apart or short circuit the batteries.
• Do not attempt to recharge alkaline or manganese batteries.
• Do not use batteries if the covering has been peeled off.
• Do not heat or expose to fl ame.
• Do not leave the battery(ies) in an automobile exposed
to direct sunlight for a long period of time with doors and
windows closed.
• Mishandling of batteries can cause electrolyte leakage, which
may cause a fi re.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
RQTX1147-1B_gb.indd 3RQTX1147-1B_gb.indd 3 3/30/2010 10:24:11 AM3/30/2010 10:24:11 AM
