Before Use

-7-

[TALK] Button is pressed, the built-in

microphone does not operate.

-21-

≥When connecting the pin plug of the Free

Style Remote Controller with Mic to this

socket, plug it in as far as it goes.

≥A compatible plug-in powered microphone

can be used.

≥The microphone may make noises

depending on the type of it. In this case, we

recommend using the battery for the Movie

Camera.

(35) Audio-Video Input/Output Socket

[AV IN/OUT] (Input function on NV-GS55

Model only)

-40-

Headphone Socket [PHONES]

≥Connecting an AV Cable to this socket

activates the Movie Camera’s built-in

speaker, but connecting a headphone, etc.

deactivates it.

≥When connecting the pin plug of the AV

Cable to this socket, plug it in as far as it

goes.

≥When using headphones, set [AV JACK] of

the [AV IN/OUT] (NV-GS55 only) or

[INITIAL] sub-menu to [OUT/PHONES]. If

you set [AV JACK] to [OUT], you may hear

noises on the right.

(36) DV Terminal [DV] (Input function on

NV-GS55 Model only)

-43-

≥Connect this to the digital video equipment.

(37) Viewfinder -13-, -57-

(38)

Eyepiece Corrector Knob -13-

(39)

Photoshot Button [PHOTO SHOT] -21-, -41-

(40)

Zoom Lever [W/T] [`VOL/JOG_] -23-

(41)

Cassette Eject Lever [OPEN/EJECT] -12-

(42)

Reset Button [RESET] -48-

(43)

Mode Dial -13-

Due to limitations in LCD production

technology, there may be some tiny bright or

dark spots on the Viewfinder screen.

However, this is not a malfunction and does

not affect the recorded picture.

START

OFF

QUICK

(37)(38)(39)(40)(41)(42)

(43)

(44)

(45)

(46)

(47)

(44)

Quick Start Recording Button

[QUICK START]

-23-

Quick Start Recording Lamp -23-

(45)

Recording Start/Stop Button -20-, -22-

(46)

Power Switch [OFF/ON] -13-, -20-, -54-

(47)

Power Lamp -13-, -20-, -32-

(48)

Mode Selector Switch

[AUTO/MANUAL/FOCUS]

-20-, -27-

(49)

Shoulder Strap Holders -11-

(50)

Grip Belt (One-touch Free Style Grip Belt)

-10-

(51)

Battery Eject Button [PUSH BATT] -10-

(52)

Battery Holder

(53) Tripod Receptacle

≥Used for mounting the Movie Camera on an

optional tripod.

ª Remote Controller

Using the wireless Remote Controller that is

supplied with the Movie Camera, most of the

Movie Camera functions can be operated from a

distance.

(54) Date/Time Button [DATE/TIME] -47-

(55)

Indication Output Button [OSD] -40-

(56)

Display Button [DISPLAY] -47-

(57)

Reset Button [RESET] -60-

(58)

Recording Button [¥REC] (Available only

with NV-GS55)

-43-

(59)

Audio Dubbing Button [A.DUB] -41-

(60)

Cursor Buttons for Variable Speed

Search Function [π, ∫]

-33-

Direction Buttons for Playback Zoom

Function [π, ∑, ∏, ∫]

-34-

(48)(49)(50)

(51)(52)

(53)

ZOOM

INDEX INDEX

SELECT

STORE

STOP

∫

OSD

DISPLAY

/REW

STILL ADV

OFF/ON

P.B . D I GI TA L

DATE/

TIME

RESET

TITLE

sVOL r

¥REC

MULTI/

P-IN-P


SHOT

START/

STOP

A.DUB

PLAY

PAU SE

FF/

STILL ADV

ENTER

61 5

;

VAR .

P.B. ZOOM

(54)

(55)

(56)

(57)

(58)

(59)

(60)

55B-ENG.book 7 ページ２００４年２月４日　水曜日　午前１１時５４分
