Manual

Before Use

-10-

1 Attach the Battery to the AC Adaptor and

charge it.

≥Since the Battery will not be charged when

the DC Input Lead is connected to the AC

Adaptor, disconnect it from the AC Adaptor.

≥The [CHARGE] Lamp lights up, and charging

starts.

≥When the [CHARGE] Lamp goes off,

charging is completed.

≥When charging the overdischarged battery,

the [CHARGE] lamp blinks at first, but the

battery is charged normally. When the

temperature of the battery is too high or low,

the [CHARGE] lamp blinks and the charging

time becomes longer than usual.

2 Attach the charged Battery to the Movie

Camera.

Disconnecting the Power Source

Set the [OFF/ON] Switch (46) to [OFF] and, while

pressing the [PUSH BATT] Button

(51), slide the

Battery or DC Input Lead upward to disconnect it.

≥For other notes concerning this item, see

-48-.

PUSH

BATT

OFF

(51)

(46)

Charging Time and Available

Recording Time

A Charging Time

B Maximum Continuous Recording Time

C Intermittent Recording Time

(Intermittent Recording Time is the available

recording time with repeated recording and

stopping actions.)

“1h10min.” indicates 1 hour and 10 minutes.

≥Battery CGA-DU07 is supplied.

≥The times shown in the table are approximate

times. The numbers indicate the recording time

when the Viewfinder is used. The numbers in

parentheses indicate the recording time when

the LCD Monitor is used. In actual use, the

available recording time may be shorter.

≥The times shown in the table are for continuous

recording at a temperature of 25oC and humidity

of 60%. If the Battery is charged at a higher or

lower temperature, the charging time may be

longer.

≥The available recording time becomes shorter if

you use both of Viewfinder and LCD Monitor

simultaneously when using the 0 Lux Night

View function, rotating the LCD Monitor

frontward to record yourself or setting

[EVF ON/AUTO] to [ON].

The One-touch Free Style Grip Belt

ª To Use as a Grip Belt

Adjust the length of the Grip Belt to the size of

your hand.

1 Detach the end of the Grip Belt.

2 Adjust the length of the Grip Belt to the size

of your hand.

CGA-DU07 A 1h30min.

B 2h15min.(1h50min.)

C 1h10min.(55min.)

CGA-DU14 A 2h45min.

B 4h30min.(3h40min.)

C 2h15min.(1h50min.)

CGA-DU21 A 3h55min.

B 6h45min.(5h30min.)

C 3h25min.(2h45min.)

55B-ENG.book 10 ページ２００４年２月４日　水曜日　午前１１時５４分
