Examine Your Oven

Unpack oven, remove all packing material and examine the oven

for any damage such as dents, broken door latches or cracks in the

door. Notify dealer immediately if oven is damaged. DO NOT install

if oven is damaged.

Placement of Oven

1. The oven must be placed on a flat, stable surface. Place the front

surface of the door 3 inches (7.6 cm) or more from the counter

top edge to avoid accidental tipping of the microwave oven

during normal use. For proper operation, the oven must have

sufficient air flow. Allow 3 inches (7.6 cm) of space on both sides

of the oven and 2 inches (5 cm) of space on top of the oven.

(a) DO NOT block air vents. If they are blocked during operation,

the oven may overheat and be damaged.

(b) DO NOT place oven near a hot, damp surface such as a gas or

electric range, or dishwasher.

(c) DO NOT operate oven when room humidity is excessive.

2.

This oven is manufactured for household use only. It is not

approved or tested for mobile vehicle, marine, or commercial use.

Installation

1. DO NOT block air vents. If they are blocked during operation,

the oven may overheat. If the oven overheats, a thermal safety

device will turn the oven off. The oven will remain inoperable

until it has cooled.

2. If the oven is designed for installation into a wall cabinet,

only use the proper Panasonic trim kit available from a local

Panasonic dealer, or online from the Panasonic Canada eStore.

Follow all instructions packed with the trim kit.

3. Use of a non-Panasonic trim kit will void the Manufacturer’s

warranty for the Microwave oven.

WARNING: IMPROPER USE OF THE GROUNDING

PLUG CAN RESULT IN A RISK OF ELECTRIC SHOCK.

Consult a qualified electrician or service person if the grounding

instructions are not completely understood, or if doubt exists as to

whether the appliance is properly grounded. If it is necessary to use

an extension cord, use only a three-wire extension cord that has a

three-prong polarized grounding plug, and a three-slot receptacle

that will accept the plug of the appliance. The marked rating of the

extension cord should be equal to or greater than the electrical

rating of the appliance.

Grounding Instructions

THIS APPLIANCE MUST BE GROUNDED.

In the event of an electrical short circuit, grounding reduces the

risk of electric shock by providing an escape wire for the electric

current. This appliance is equipped with a cord having a grounding

wire with a grounding plug. The plug must be plugged into an

outlet that is properly installed and grounded.

• Plug into properly

installed and grounded

three-prong outlet.

• DO NOT remove ground

prong.

• DO NOT use an adapter.

Power Supply

1. A short power-supply cord is provided to reduce the risks

resulting from becoming entangled in or tripping over a longer

cord.

2. Longer cord sets or extension cords may be used if care is

exercised in their use. DO NOT let cord hang over edge of a

table or counter.

3. If a long cord or extension cord is used,

• The marked electrical rating of the cord set or extension

cord should be at least as great as the electrical rating of the

appliance.

• The extension cord must be a grounding-type 3-wire cord.

• The longer cord should be arranged so that it will not drape

over the counter top or tabletop where it can be pulled on by

children or tripped over accidentally.

Wiring Requirements

1. The oven must be operated on a SEPARATE CIRCUIT. No other

appliance should share the circuit with the microwave oven.

If it does, the branch circuit fuse may blow or the circuit breaker

may trip.

2. The oven must be plugged into at least a 15 A or 20 A, 120V,

60 Hz GROUNDED OUTLET. (Beginning in 2017, all new

construction and all renovated single family homes must

have at least a 20 A, 120 VOLT, 60 Hz GROUNDED OUTLET).

Where a standard two-prong outlet is encountered, it is the

responsibility and obligation of the consumer to have it replaced

with a properly grounded three-prong outlet.

3. The VOLTAGE used must be the same as specified on this

microwave oven (120V, 60Hz). Using a higher voltage is

dangerous and may result in a fire or oven damage. Using

a lower voltage will cause slow cooking. Panasonic is NOT

responsible for any damages resulting from the use of the oven

with any voltage other than specified.

TV / RADIO / WIRELESS EQUIPMENT INTERFERENCE

This product has been tested and found to comply with the limits

for Microwave Oven. This product can radiate radio frequency

energy, which could cause interference to such products as radio,

TV, baby monitor, cordless phone, Bluetooth, wireless router, etc.,

which can be confirmed by turning this product off and on. If

present, the user is encouraged to try to correct by taking one or

more of the following countermeasures:

(1) Increase the spacing distance between the microwave oven and

other product receiving the interference.

(2) If possible, use a properly installed receiver antenna and/or

reorient the receiving antenna of the other product receiving the

interference.

(3) Plug the microwave oven into a different outlet from the other

product receiving the interference.

(4) Clean door and sealing surfaces of the oven. (See Care and

Cleaning of Your Microwave Oven)

3-Pronged Plug

Ground Plug

3-Prong Receptacle

Installation and Grounding Instructions
