- 4 -

Placement of the Oven

Locate the oven on a smooth, flat and stable surface.

There should be no gap between the table surface and

the bottom of the oven. Do not place the oven in a hot

or damp area, ie. near a stove, sink or directly above

heat lamps on a serving line. Free airflow around the

oven is important. There is a possibility of a small

amount of interference with weak broadcast signals if

the microwave oven is too close to a radio or TV.

Grounding Instructions

This oven must be grounded electrically. In the event of

an electrical short circuit, grounding reduces the risk of

electric shock by providing an escape wire for the

electric current. The appliance is equipped with a cord

having a grounding wire with a grounding plug. The

plug must be plugged into an outlet that is properly

installed and grounded.

WARNING — improper use of the grounding plug can

result in a risk of electric shock.

Consult a qualified electrician or service person if the

grounding instructions are not completely understood,

or if doubt exists as to whether the appliance is

properly connected.

If it is necessary to use an extension cord, use only a

three wire extension cord that has a three blade

grounding plug, and a three slot receptacle that will

accept the plug on the appliance. The marked rating of

the extension cord should be equal to or greater than

the electrical rating of the oven.

Protective Film Removal

A blue protective film is used to prevent scratching of

the outer case during transportation. Peel the film from

the exterior of the oven before installation or use.

Wiring Requirements

No other appliance should share the circuit with the

microwave oven. If it does, the branch circuit fuse may

overload and either cause the oven to heat slower than

expected or blow the fuse.

A. For Models No. NE-12521/NE-12523

The oven must be on a SEPARATE, 20 amp,

60 Hz-120 V GROUNDED CIRCUIT.

NEMA#

5-20P

120 V

Grounded

Outlet

NEMA# 5-20R

B. For Models No. NE-17521/NE-17523/NE-21521/

NE-21523

1. This oven must be on a separate, 60 Hz

GROUNDED CIRCUIT - minimum 15 amps for

Models No. NE-17521/NE-17523; minimum

20 amps for Models No. NE-21521/NE-21523.

2. The microwave ovens are built to operate on 2

different voltages (230-240 V or 208 V).

Models No.

NE-17521/NE-17523

Models No.

NE-21521/NE-21523

NEMA#

6-15P

NEMA#

6-20P

208 V/230-240 V

Grounded Outlet

NEMA# 6-15R or 6-20R

208 V/230-240 V

Grounded Outlet

NEMA# 6-20R

Caution

1. Do NOT attempt to tamper with or make any

adjustments or repairs to the door, control panel

housing, safety interlock switches or any other part

of the oven. Do NOT remove the outer panel of the

oven. Repairs should only be done by a qualified

service person.

2. Do NOT operate the oven empty. The microwave

energy will reflect continuously throughout the oven

if no food or water is present to absorb energy.

3. If a fire occurs in the oven, press the Stop/Reset

pad and LEAVE THE DOOR CLOSED. Disconnect

the power cord, or shut off the power at the fuse or

circuit breaker panel.

4. Do NOT attempt to dry clothes, newspapers or

other materials in the oven, as they may catch on

fire.

5. Do NOT use recycled paper products, as they may

contain impurities which may cause sparks and/or

fires.

6. Do NOT use newspapers or paper bags for cooking.

7. Do NOT hit or strike the control panel. Damage to

controls may occur.

8. POT HOLDERS may be needed when removing

food from the oven. Heat is transferred from the hot

food to the container.

9. Do NOT store flammable materials next to, on top

of, or in the oven. It could be a fire hazard.

10. Do NOT operate the oven without the spatter

shields (located in the top of inner cavity) in place.

Installation and GROUNDING INSTRUCTIONS
