Manual Panasonic CS-TZ42ZKEW Air Conditioner

Need a manual for your Panasonic CS-TZ42ZKEW Air Conditioner? Below you can view and download the PDF manual for free in English. This product currently has 7 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

Loading…

3
EN
Quick Guide
Indicators
A
Clock setting
Inserting the batteries
B
Basic operation
1
2
3
1
Pull out the back cover of
remote control.
2
Insert AAA or R03 batteries.
3
Close the cover.
1
Press
CLOCK
, then press
to set the time
.
Press
CLOCK
for approximately 5 seconds to show the time
as 12-hour (am/pm) or 24-hour.
2
Press to con rm.
POWER
1
Press to start/stop the
operation.
When the unit is ON, disappears
from the remote control display.
DRY
AUTO HEAT
COOL
2
Press to select the
desired mode.
Up
Down
3
Press TEMP UP, TEMP DOWN to
select the desired temperature.
Selection range:
16.0 °C ~ 30.0 °C / 60 °F ~ 86 °F.
Press for approximately 10 seconds to show the temperature as
°C or °F.
nanoeX
POWER
TIMER
nanoeX
C
B
A
C
To connect to a network
Press to turn the Wireless LAN feature ON or OFF.
For Wireless LAN Module operation setup, please refer to Setup
Instructions Web Manual.
If the Wireless LAN LED blinks continuously and you do not want
to use the app, press the Wireless LAN button to turn it off .
System Overview / Quick Guide
Download manual in English (PDF, 2.12 MB)
(Consider the environment and only print this manual if it is really necessary)

Loading…

Rating

Let us know what you think about the Panasonic CS-TZ42ZKEW Air Conditioner by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.
Are you satisfied with the Panasonic CS-TZ42ZKEW Air Conditioner?
Yes No
Be the first to rate this product
0 votes

Join the conversation about this product

Here you can share what you think about the Panasonic CS-TZ42ZKEW Air Conditioner. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Panasonic CS-TZ42ZKEW Air Conditioner. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Panasonic. They might be able to provide an original manual. Are you looking for the manual of your Panasonic CS-TZ42ZKEW Air Conditioner in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand Panasonic
Model CS-TZ42ZKEW
Category Air Conditioners
File type PDF
File size 2.12 MB

All manuals for Panasonic Air Conditioners
More manuals of Air Conditioners

Frequently Asked Questions about Panasonic CS-TZ42ZKEW Air Conditioner

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

How often should I clean or replace the filters in my air conditioner? Verified

It's advisable to check the filters of your air conditioner 4 times a year. Dirty filters can be cleaned with the use of a vacuum cleaner or can be washed, depending on which type they are. During maintenance a professional should judge whether it is time to replace the filters.

This was helpful (3004) Read more

What does BTU stand for? Verified

BTU stands for British Thermal Unit. This is unit to indicate the capacity to cool.

This was helpful (1130) Read more

Does every air conditioner also function as a dehumidifier? Verified

The cold air produced by an air conditioner often has a relatively low humidity. However, the effect is less than when using an actual dehumidifier. Some air conditioners do have a special feature to dehumidify the air.

This was helpful (898) Read more

What is R-410A? Verified

R-410A is a cooling agent that is used in appliances that cool up to 0°C, like refrigerators and air conditioners. It is the replacement of older cooling agents and does not damage the ozon layer.

This was helpful (636) Read more

What is the best place to mount the indoor unit of a split-type air conditioner? Verified

This depends on the space, but in general the following rules can be followed. Make sure that there is nothing obstructing the airflow. Make sure the location is accessible for maintenance. Mount the unit at least 2 meters from the ground.

This was helpful (450) Read more

Does an air conditioner have a negative influence on air quality? Verified

If the air conditioner has been properly maintained then it will have no influence on air quality. If for example a filter hasn't been replaced for a long time, or other maintenance has not been performed, than an air conditioner can produce dirty air.

This was helpful (441) Read more

Can I place my mobile air conditioner in a cabinet to get it out of sight? Verified

No, absolutely not. A mobile air conditioner needs space to allow airflow and air intake. In a small space the device can overheat.

This was helpful (439) Read more
