Manual Ozito TSF-1211 Table Saw

Need a manual for your Ozito TSF-1211 Table Saw? Below you can view and download the PDF manual for free in English. This product currently has 0 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to

the online manual.

1. Side table extension

2. Rear table extension

3. Sliding mitre gauge

4. Dust extractor hose

5. Blade guard

6. Rip fence

7. Support strut

8. Stabilising bracket

9. Push stick

10. Guide rail

11. Table insert

12. Rip fence lever

13. ON/OFF switch

14. Bevel lock

15. Blade height & Bevel

adjustment

16. Bevel scale

TABLE SAW

KNOW YOUR PRODUCT

54 6

1. ADJUSTMENTS

For detailed assembly instruction see Assembly

Manual.

SETUP & PREPARATION

0º 5º

10º

15º

20º

25º

22.5º

30º

45º

WARNING! ENSURE THE TOOL IS SWITCHED OFF AND

DISCONNECTED FROM THE POWER SUPPLY BEFORE

PERFORMING ANY OF THE FOLLOWING PROCEDURES.

Cutting Depth

Bevel Angle

1. To lower the blade for a

smaller depth of cut, rotate

the blade height & bevel

adjustment clockwise.

3. Rotate the blade height

& bevel adjustment to the

desired angle using the

bevel scale.

2. Push and hold the blade

height & bevel adjustment

dial in to engage the bevel

gear.

2. To raise the blade for a

larger depth of cut, rotate

the blade height & bevel

adjustment anti-clockwise.

4. Release the blade height & bevel adjustment dial, secure in place by

rotating the bevel lock clockwise.

1. Loosen the bevel lock by

rotating anti-clockwise.

13 15 16

Download manual in English (PDF, 3.97 MB)

(Consider the environment and only print this manual if it is really necessary)
