Manual Ozito SGP-5000 Paint Sprayer

Need a manual for your Ozito SGP-5000 Paint Sprayer? Below you can view and download the PDF manual for free in English. This product currently has 3 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to

the online manual.

1 Nozzle

2 Air Cap

3 Paint Head

4 On/Off Trigger

5 Spray Regulator Dial

6 Paint Pot

7 Locking Lever

8 Soft Grip Handle

9 Spray Gun Body

10Airlter

SPRAY GUN

KNOW YOUR PRODUCT

1 2 3 4 5

6 7

11 12 13 14 15 16

8 9 10

1. ASSEMBLY

11 Cleaning Needle

12 Cleaning Brush

13 Viscosity Cup

14 Nozzles x 2

15 Paint Pot Lid

16 Fluid Needle Removal Tool

ACCESSORIES

SETUP & PREPARATION

1 Insert the paint head into the gun body by aligning the

arrows on the neck of the paint head and body.

Note: Ensure the locking lever is rotated out of the way to

avoid damaging the locking lever.

1 When spraying horizontal

or low objects turn the

suction tube to the front.

3 Rotate the locking lever

forward to secure the paint

head.

2 Rotate the paint head

clockwise into the correct

orientation.

2 When spraying overhead

objects turn the suction

tube to the back.

Inserting the Paint Head

Aligning the Suction Tube

WARNING! ENSURE THE TOOL IS DISCONNECTED FROM

THE POWER SUPPLY BEFORE PERFORMING ANY OF THE

FOLLOWING OPERATIONS.

Download manual in English (PDF, 2.09 MB)

(Consider the environment and only print this manual if it is really necessary)
