Manual

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to

the online manual.

1 Power On LED

2 Thermal Overload LED

3 Digital Display

4 Welding Current Control

5 Negative Output Terminal

6 Positive Output Terminal

7 On/OSwitch(rear)

INVERTER ARC WELDER

KNOW YOUR PRODUCT

8 Earth Clamp

9 Arc Electrode Holder

10 Hammer Brush

11 Welding Mask

SETUP & PREPARATION

8 9 10 11

2 3 4 5 6 7

1. WELDING MASK

Fitting the Welding Screen

1 Insert the glass retaining pins

into the holes from the outside

ofthemaskandthentthe

retaining clips from the inside.

Rotate the clip to allow the

glass to be inserted.

3 Bend the sides and top of the

welding mask inwards and clip

together at the corners.

2 First insert the clear glass

into the recess of the welding

mask, followed by the dark

safety glass and then the

plastic frame.

Rotate the retaining clips to

lock in position.

4 Insert the 3 screws into the

handle mounting holes from

the outside. Fit the handle

onto the screws from inside

the mask and then secure

using the 3 nuts.

Theincludedweldingmaskmustbettedwiththeweldingscreenand

handle before using for welding.

MIN

120A

INVERTER ARC WELDER

Download manual in English (PDF, 2.66 MB)

(Consider the environment and only print this manual if it is really necessary)
