Talking Blood Pressure Monitor

Model:

BPW810N

USER MANUAL

INTRODUCTION

Thank you for selecting the Oregon Scientifi c

TM

Thank you for selecting the Oregon Scientifi c

Thank you for selecting the Oregon Scientifi c

TalkingWrist

Type Blood Pressure Monitor (BPW810N). The (BPW810N)

features voice announcement and playback of blood

pressure measurements for added convenience and has been

designed to provide you with many years of reliable service.

The unit can help you measure and track the following metrics:

• Systolic pressure

• Diastolic pressure

• Mean arterial pressure

• Pulse rate

• Historic record of up to 30 measurements per user

(maximum 2 users)

Readings taken by the blood pressure monitor are

equivalent to those obtained by a trained observer using

the cuff and stethoscope auscultation method. Clinical

performance were successfully done against ANSI/

AAMI SP10 and international protocol, and the B.H.S.

(British Hypertension Society) has rated this product

“recommended for clinical and home use”, the highest

grading available for blood pressure monitors.

Please refer to BHS website http://www.bhsoc.org/bp_

monitors/automatic_wrist.stm

This manual contains important safety and care information,

and provides step-by-step instructions for using the product.

Read the manual thoroughly before using the product.

KEY FEATURES

FRONT VIEW

1. TALK / VOLUME button

2. LCD

3.

ON / OFF button

4. Speaker

5.

USER 1 / UP ARROW button

6.

USER 2 / DOWN ARROW button

7. SET button

REAR VIEW

1. Wrist cuff

2. Battery compartment

LCD SYMBOLS

SAFETY AND CARE INSTRUCTIONS

SAFETY PRECAUTIONS

Please observe the following safety precautions when

setting up and using your blood pressure monitor.

• This device is intended for adult use only.

• This device is intended for non-invasive measuring

and monitoring of arterial blood pressure. It is not

intended for use on extremities other than the wrist

or for functions other than obtaining a blood pressure

measurement.

• Do not confuse self-monitoring with self-diagnosis.

This unit allows you to monitor your blood pressure.

Do not begin or end medical treatment based solely on

the measurements of this device. Consult a physician

for treatment advice.

• If you are taking medication, consult your physician

to determine the most appropriate time to measure

your blood pressure. Never change a prescribed

medication without consulting your physician.

• This unit is not suitable for continuous monitoring

during medical emergencies or operations.

• If the cuff pressure exceeds 40 kPa (300 mmHg),

the unit will automatically defl ate. Should the cuff not

defl ate when pressures exceeds 40 kPa (300mmHg),

detach the cuff from the wrist and press the

button

to stop infl ation.

• To avoid measurement errors, carefully read this

manual before using the product.

CARING FOR YOUR BLOOD PRESSURE MONITOR

To ensure you receive the maximum benefi t from using

this product, please observe the following care guidelines.

• When not in use, store the unit in a dry place away

from direct sunlight.

User Shows which user

profi le (1 or 2 is

being displayed)

Memory

If “MEM” shows,

the displayed

measurement value

is from the memory

and not necessarily

from the last reading

SYMBOL DESCRIPTION EXPLANATION

Systolic pressure

The highest blood

pressure measured

Diastolic pressure

The lowest blood

pressure measured

Time (hour: minutes)

Current time

Mean arterial

pressure

Average blood

pressure measured

(see “What is Mean

Arterial Pressure

(MAP)?” for more

information)

Pulse Pulse rate per

minute

Weak battery

Batteries are low and

need to be replaced

Infl ating

Unit is infl ating

with air to obtain

the needed level of

pressure

Defl ating

Wrist cuff air is

exhausting or

defl ating

Millimeter(s) of

mercury

Measurement unit

for blood pressure

Kilopascal

Measurement unit

for blood pressure

Voice activation

Voice announcing

your blood pressure

measured

• Do not immerse the unit in water. If it comes in contact

with water, dry it immediately with a soft lint-free cloth.

• Use a soft, slightly moistened cloth to wipe off the unit

and cuff. Do not use abrasive or corrosive cleaning

agents, as these may cause damage.

• Remove the batteries whenever you are planning to

store the unit for a long period of time.

• When replacing batteries, use new batteries as

specifi ed in this user manual. Do not mix new and old

batteries.

• Do not place objects such as stickers on the wrist cuff

or unit, as these may impair the measurement.

• Do not subject the unit to excessive force, shock, dust,

temperature changes, or humidity. Such treatment

may result in malfunction, a shorter electronic life

span, damaged batteries, or distorted parts.

• Do not tamper with the internal components. Doing

so will terminate the product warranty and may cause

damage.

• The unit contains no user- serviceable parts.

• If you no longer need to use this product, protect the

environment by bringing it to your dealer or designated

collection point for proper disposal.

ABOUT BLOOD PRESSURE

What is blood pressure?

Blood pressure is the force generated by the blood against the

walls of arteries during cardiac contraction and relaxation

(e.g., the pumping action of the heart).

What are systolic pressure and diastolic pressure?

When ventricles contract and pump blood out of the heart,

blood pressure reaches its maximum value. This highest

pressure in the cycle is known as systolic pressure. When

the heart relaxes between heartbeats, the lowest blood

pressure is diastolic pressure.

What is mean arterial pressure (MAP)?

The mean arterial pressure (MAP) is the average

pressure that forces blood through

the arteries. It is not

the average of the systolic and diastolic blood pressure;

rather, MAP corresponds to a state of balance between the

compressive and expansive forces acting on the arterial

wall when there is no distension outward or inward. MAP is

an excellent way to evaluate the stress on the walls of your

blood vessels, and can be used to evaluate excessive load

on the cardiovascular system. Show your MAP history to

your doctor to provide additional information that may help

him or her understand your situation.

Why measure your blood pressure?

Blood pressure measurement can highly refl ect one’s

health condition. High blood pressure is potentially linked

to serious illnesses such as stroke, heart disease and

kidney failure.

Since there is no symptom most of the time, many

hypertensive people do not realize they are at risk until

their health is seriously threatened.

What is the standard blood pressure classifi cation?

Figure 3 illustrates the blood Pressure classifi cation made

by World Health Organization (WHO) and International

Society of Hypertension (ISH) in 1999.

Reference material: 1999 World Health Organization-

International Society of Hypertension Guidelines for the

management of hypertension, Journal of Hypertension,

1999, 17(2): 151-183.

NOTE

• Blood pressure is considered high when either the

diastolic or systolic blood pressure value exceeds the

normal range. When a patient’s systolic and diastolic

blood pressures fall into different categories, the

higher category should apply.

• Only a physician can tell you your

normal blood

pressure range and the point at which you are at risk.

Why does my blood pressure fl uctuate throughout the day?

Individual blood pressure varies greatly both on a daily and

a seasonal or temperature basis. These variations may be

more pronounced in hypertensive patients. Normally the

blood pressure rises while at work and is at its lowest

during sleep.

The graph below illustrates the variations over a single day

with measurement taken every 5 minutes. The thick line

represents sleep time. The rises in blood pressure at 4PM

(A in the graph) and 12AM (Bin the graph) correspond to

an attack of pain and sexual intercourse (Beven, Honour &

Stott, Clin. Sci. 36:329, 1969).

HOW THE BLOOD PRESSURE MONITOR WORKS

This product uses the Oscillometric Measuring method to

detect your blood pressure. Before every measurement,

the unit establishes a “zero pressure”equivalent to the air

pressure.

Then it starts infl ating the wrist cuff to 180mmHg or higher

until it senses that it has blocked your blood in the artery.

After that, the defl ation process starts, during which time

the unit detects pressure oscillations generated by beat-

to-beat pulsatile, which is used to determine the systolic,

mean and diastolic pressure, and also your pulse rate.

Any motion during this period will result in an incorrect

measurement. After all readings are determined and

displayed on the LCD, the measurement is fi nished

and

the wrist cuff automatically defl ates.

GETTING STARTED

INSTALLING AND REPLACING THE BATTERIES

1. Slide off the battery cover.

2. Install the batteries by matching the correct polarity, as

shown below. Always use the correct battery type (2

alkaline LR03 AAA-size).

3. Replace the cover.

NOTE Replace the batteries whenever the weak battery

mark

shows, the display is dim, or the display does not

illuminate when the power is on. Replace all the batteries

at the same time - it is dangerous to mix old and new

batteries.

Contact your local waste disposal authority for instructions

on how to dispose of used batteries. Used batteries can be

harmful to the environment, and should not be thrown out

with household trash.

SETTING DATE, TIME AND MEASUREMENT UNITS

It is important to set the clock before using your blood

pressure monitor, so that a time stamp can be assigned to

each record that is stored in the memory.

1. When the unit is off, press and hold SET for 2 seconds

to enter the setting mode.

2. The setting order is as follows: 12/24 hour format,

hour, minute, year, month/day or day / month format,

month, date, and measurement unit (kPa or mmHg).

3. Press

or

or

to increase / decrease a value or change the

to increase / decrease a value or change the

setting.

4. Press SET to accept the change and switch to the next

setting.

5. When you are fi nished, press to exit the setup menu.

to exit the setup menu.

POSITIONING THE WRIST CUFF

It is important to properly position the wrist cuff to ensure

that you receive an accurate reading.

1. Remove all accessories (watch, bracelet, etc.) from

your left wrist. If your physician has diagnosed you with

poor circulation in your left arm, use your right wrist.

2. Roll or push up your sleeve to expose the skin.

3. Apply the cuff to your left wrist with your palm facing up.

4. Position the edge of the cuff about 0.4 inches (1cm)

from the bottom of your palm.

5. Fasten the wrist cuff around your wrist, leaving no

extra room between the cuff and your skin. If the cuff

is too loose, the measurement will not be accurate.

NOTE Graphics may not exactly match product.

VOICE PLAYBACK OF BLOOD PRESSURE

MEASUREMENTS

The BPW810N features voice playback during and after blood

pressure measurement results, as well as general

instructions to help you prepare for taking measurements.

When the unit has fi nished taking your measurement,

your blood pressure readings, pulse and blood pressure

classifi cation are announced.

If you want to repeat the announcement, simply press

TALK / VOLUME.

Anytime you recall a measurement record from memory,

it will also be announced. Press TALK / VOLUME if you

need to repeat the playback of any record.

VOLUME CONTROL

To adjust the volume level:

1. Press and hold TALK / VOLUME until volume level

fl ashes on the LCD.

2. Press TALK / VOLUME to adjust volume level.

3. Press

when you have fi nished adjusting the volume.

when you have fi nished adjusting the volume.

NOTE When volume level 0 is selected, the unit is on mute

and you will not hear any voice messages announced.

TAKING A BLOOD PRESSURE MEASUREMENT

You can choose to take your blood pressure while sitting or lying

down. Below are some helpful tips for taking a measurement:

• Be sure to set the clock before taking your fi rst

measurement, or whenever you replace the batteries,

so that the date and time are stored in the memory

with your history. For instructions, refer to "Setting date,

time and measurement units" section.

• It is important to relax when taking your blood pressure.

Try to take a 15-minute rest before you begin.

• Do not lean backward or bend your wrist inward while

taking a measurement.

• Avoid talking or moving your fi ngers and hand while

taking a measurement. Rapid movements or other

1 2

(MUTE) (VOLUME IS

LOW)

(VOLUME IS

HIGH)

kP

a

Grade 3 hypertension(severe)

Grade 2 hypertension(moderate)

Systolic blood pressure (mmHg)

Grade 1 hypertension(mild)

Subgroup: borderline

High-normal Blood Pressure

)gHmm(erusserpdoolbcilotsaiD

Normal Blood Pressure

Optimal Blood

Pressure

120

80

85

90

95

100

110

130 140 150 160 180

1

2

3

5

4

6

7

Consult your physician to obtain these values. If the

measurements taken with these products fall outside

the range, consult your physician.

•

Rating

More about this manual

We understand that it’s nice to have a paper manual for your Oregon BPW810N Blood Pressure Monitor. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Oregon. They might be able to provide an original manual. Are you looking for the manual of your Oregon BPW810N Blood Pressure Monitor in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

All manuals for Oregon Blood Pressure Monitors
More manuals of Blood Pressure Monitors

Frequently Asked Questions about Oregon BPW810N Blood Pressure Monitor

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Related products

Manual

Oregon BPU321OS Blood Pressure Monitor

Manual

Boso Medicus Vital Blood Pressure Monitor

Manual

Medisana BU 582 Blood Pressure Monitor

Manual

Microlife BP B1 Classic Blood Pressure Monitor

Manual

Hoffen KF-65A Blood Pressure Monitor

Manual

SilverCrest IAN 366722 Blood Pressure Monitor

Manual

Rossmax R43 Blood Pressure Monitor

Manual

Innoliving INN-006 Blood Pressure Monitor

Related categories
