Manual Orbegozo TF 0133 Fan

Need a manual for your Orbegozo TF 0133 Fan? Below you can view and download the PDF manual for free in English. This product currently has 2 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

TF 0123/133/143

funcionamiento.

• Apague todos los interruptores y desenchufe el aparato si

no va a usarlo durante un cierto periodo de tiempo.

DESCRIPCIÓN

1. Aspa del ventilador.

2. Eje.

3. Cierre de la rejilla.

4. Base.

5. Rejilla trasera.

6. Botón de oscilación.

7. Cubierta trasera del motor.

8. Soporte de inclinación

9. Eje de inclinación

10. Cuello.

11. Rejilla delantera.

12. Tuerca del aspa.

13. Control de velocidad.

14. Indicador LED.

MONTAJE

- Compruebe que el ventilador está desenchufado y el control de velocidad en la posición 0.

- Introduzca la rejilla trasera en el eje del motor, coloque la tuerca suministrada para fijar la rejilla trasera.

- Coloque el aspa en el eje y coloque la tuerca correspondiente. Compruebe manualmente que el aspa gira

correctamente. Para el modelo TF 0123 coloque el aspa en el eje y empuje hasta que quede bien encajada.

- Coloque la rejilla delantera e instale el aro de plástico alrededor de las rejillas. Apriete el tornillo de la

rejilla para fijar el aro.

- En el TF 0123, el botón de oscilación ha de ser montado con el tornillo que se suministra, atorníllelo en su

posición.

FUNCIONAMIENTO

- Coloque el ventilador en el lugar deseado. Compruebe que el control de velocidad está en la posición 0.

Enchufe el ventilador a la corriente eléctrica.

Download manual in English (PDF, 0.81 MB)

(Consider the environment and only print this manual if it is really necessary)

Rating

Let us know what you think about the Orbegozo TF 0133 Fan by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Orbegozo TF 0133 Fan?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Orbegozo TF 0133 Fan. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Orbegozo TF 0133 Fan. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Orbegozo. They might be able to provide an original manual. Are you looking for the manual of your Orbegozo TF 0133 Fan in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.
