Manual

Removing metal grease filter

1. Fold the filter cover upwards.

Notes

■ The opening angle of the filter cover is restricted to approx.

80°. Do not open the filter cover any further, otherwise the

hinges may be damaged.

■ The filter cover locks in any position.

2. Remove the two metal grease filters under the filter cover and

the metal grease filter on the underside of the appliance.

Unfasten the lock, fold the metal filter forwards and remove it

from the bracket.

Note: Grease can accumulate at the bottom of the metal

grease filter. Hold the metal grease filter level, otherwise

grease will drip out.

3. Clean the metal grease filter.

4. After removing the filters, clean the inside of the appliance.

5. Clean the filter cover.

Installing the metal mesh grease filter

1. Insert the two metal grease filters under the filter cover with

the lock facing downwards.

Insert the metal grease filters on the underside of the

appliance.

2. Fold the metal grease filters inwards, locking them in place.

3. Close the filter cover.

Changing the activated charcoal filter (only in

circulating-air mode)

In order to guarantee efficient odour filtration, the filter must be

serviced regularly.

The activated charcoal filters must be replaced at least every

4 months.

Notes

■ The activated charcoal filters are not included in the delivery.

The activated charcoal filters can be obtained from specialist

retailers, from our after-sales service or from the Online Shop.

■ The activated charcoal filters cannot be cleaned or

reactivated.

1. Remove metal grease filter: See above.

2. Turn the old activated charcoal filter and pull away from the

bracket.

3. Push the new activated charcoal filter onto the bracket and

turn.

4. Fit the metal grease filter: See above.

Trouble shooting

Malfunctions often have simple explanations. Please read the

following notes before calling the after-sales service.

: Risk of electric shock!

Incorrect repairs are dangerous. Repairs may only be carried

out and damaged power cables replaced by one of our trained

after-sales technicians. If the appliance is defective, unplug the

appliance from the mains or switch off the circuit breaker in the

fuse box. Contact the after-sales service.

Malfunction table

--------

Problem Possible cause Solution

The appliance

does not work

The plug is not

plugged in.

Connect the appliance to

the electricity supply

Power cut Check whether other

kitchen appliances are

working

Faulty fuse Check in the fuse box to

make sure that the fuse for

the appliance is OK

The button illu-

mination does

not work.

The control unit

is faulty.

Call the aftersales service.

The lighting

does not work.

The bulbs are

faulty.

For information on chang-

ing the bulbs, see the

"Replacing Bulbs" section.
