Manual Neff D39E49S0 Cooker Hood

Manual

6

Operating modes

This appliance can be used in exhaust-air mode or circulating-

air mode.

Exhaust air mode

Note. The exhaust air must not be conveyed into a functioning

smoke or exhaust gas flue or into a shaft which is used to

ventilate installation rooms which contain heat-producing

appliances.

■ Before conveying the exhaust air into a non-functioning

smoke or exhaust gas flue, obtain the consent of the heating

engineer responsible.

■ If the exhaust air is conveyed through the outer wall, a

telescopic wall box should be used.

Circulating-air mode

Note: To bind odours in circulating-air mode, you must install

an activated carbon filter. The different options for operating the

appliance in circulating-air mode can be found in the brochure.

Alternatively, ask your dealer. The required accessories are

available from specialist outlets, from customer service or from

the Online Shop. The accessory numbers can be found at the

end of the instructions for use.

Operating the appliance

These instructions apply to several appliance variants. It is

possible that individual features are described which do not

apply to your appliance.

Note: Switch on the extractor hood when you start cooking and

switch it off again several minutes after you have finished

cooking. This is the most effective way of removing the kitchen

fumes.

Control panel

Setting the fan

Note: Always adjust the fan strength to meet current conditions.

If there is a large build-up of steam or fumes, select a high fan

setting.

Switching on

Press button 1, 2 or 3.

To confirm the setting, the 0 button and the set fan speed light

up.

Switching off the appliance

Press the 0 button.

Fan run-on time

The fan run-on is possible in any fan speed.

1. First, press the button for the required fan speed 1, 2 or 3.

2. To activate the fan run-on, press and hold the % button for 2

seconds.

To confirm the setting, the 0 button and the set fan speed

flash.

3. To end the fan run-on early, press the 0 button.

Notes

■ The run-on time for all fan speeds is 30 minutes. Once this

time has elapsed, the ventilation and lighting automatically

switch off.

■ The fan speed can be changed during the run-on time.

Intensive setting

You can use the intensive setting if there is a large build-up of

odours and fumes/vapours.

1. To activate the intensive setting, press and hold the g button

for 2 seconds.

To confirm the setting, the 0 button lights up and the

g button

flashes.

2. To end the intensive setting early, press the 0 button.

Note: The time of the intensive setting is 6 minutes. Once this

time has elapsed, the appliance switches back to the fan

setting that was previously set.

Lighting

The lighting can be switched on and off independently of the

ventilation.

Press the

@ button.

Setting the brightness

When switching on the lights, press and hold the

@ button for

2 seconds. The brightness is reduced.

Note: When switching on the lights again, the brightness is set

to maximum once again.

The air which is drawn in is cleaned by the

grease filters and conveyed to the exterior

by a pipe system.

The air which is drawn in is cleaned by the

grease filters and an activated carbon filter and

conveyed back into the kitchen.

Explanation

0 Fan off

1 Fan speed 1

2 Fan speed 2

%

Fan run-on

3 Fan speed 3

g

Intensive setting

B

Light on/off
