Manual

Installation

Before beginning any installation work ensure

the mains power has been turned off.

Extracted Air Installation

1 Using a Phillips screwdriver fix the ducting

hose connector onto the air outlet of the hood.

2 Connect the hose (not supplied) to the

air duct. Use the adaptor provided to

connect to a 125mm hose (not supplied).

(refer to fig.1)

fig.1 fig.2

3 The ducting can pass through your wall

to the outside.

4 If you operated the cooker hood in

recirculation mode, fit the metal plate in

the chimney to prevent the exhaust air

from reaching the ceiling.(refer to fig.2)

Stencil

Use the stencil provided to help position the

hood onto the wall directly below the ducting.

NOTE: Take extreme care when drilling holes

into your wall to avoid hidden electrical wiring.

1 With the stencil positioned on the wall,

drill 4 holes onto the back wall. Push 4

raw plugs into the drill holes and partially

screw in the top 2 screws.

2 Fix the hood onto the wall by positioning

the upper 2 screws through the key holes

on the back of the hood.

3 Attach the lower part of the hood by

removing the filter panels to gain access

to the lower safety screw holes.

Attaching the Chimney flue wall bracket

1 Using the wall bracket as a template, drill

2 holes into the wall and push raw plugs

into the drill holes.

2 Place the wall bracket over the raw plugs

and screw into position.

3 Screw the inner chimney flue section to the

wall bracket.

Adjusting the telescopic hood

The telescopic chimney flue can be adjusted in

height to fit your ceiling once fully attached to

the wall.

30mm

Metal plate
