SPECIFICATIONS

Model DUS108 DUS158

Rated voltage D.C. 18 V

Tank capacity 10 L 15 L

Hose length 1.7 m

Spray wand length 60 cm

Max. working pressure 0.5 MPa

Working pressure with vertical type

2-head nozzle

Approx. 0.34 MPa

Flow rate with vertical type 2-head

nozzle

Approx. 0.90 L/min

Working pressure with weedkiller

nozzle

Approx. 0.12 MPa

Flow rate with weedkiller nozzle Approx. 1.70 L/min

Nozzle tting screw G 1/4"

Technical the volume of total residual ≤ 200 ml

Dimensions (L × W × H) 317 × 237 × 437 mm 317 × 237 × 517 mm

Weight when empty 5.6 - 5.9 kg 5.9 - 6.2 kg

Weight when full 15.6 - 15.9 kg 20.9 - 21.2 kg

• Due to our continuing program of research and development, the specications herein are subject to change

without notice.

• Specications may di󰀨er from country to country.

• The weight may di󰀨er depending on the attachment(s), including the battery cartridge. The lightest and heaviest

combination, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Battery cartridge BL1820B / BL1830B / BL1840B / BL1850B / BL1860B

Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF / DC18SH

•

Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.

WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges

and chargers may cause injury and/or re.

WARNING: Do not use a corded power supply such as battery adapter or portable power pack with

this machine. The cable of such power supply may hinder the operation and result in personal injury.

Symbols

The followings are symbols used for the equipment. Be sure that you understand their meaning before use.

Wear ear protection.

Warning

Wear a breathing

mask.

Wear eye protection.

Wear safety

footwear.

Wear protective

gloves.

Do not use in the rain or leave the sprayer outdoors

while raining.

Read instruction manual.

Keep bystanderds away when spraying.

Ni-MH

Li-ion

Only for EU countries

Due to the presence of hazardous components in the

equipment, waste electrical and electronic equipment,

accumulators and batteries may have a negative

impact on the environment and human health.

Do not dispose of electrical and electronic appliances

or batteries with household waste!

In accordance with the European Directive on waste

electrical and electronic equipment and on accumula-

tors and batteries and waste accumulators and batter-

ies, as well as their adaptation to national law, waste

electrical equipment, batteries and accumulators

should be stored separately and delivered to a sep-

arate collection point for municipal waste, operating

in accordance with the regulations on environmental

protection.

This is indicated by the symbol of the crossed-out

wheeled bin placed on the equipment.
