2
COMPONENT
Wall mount anchor 6 units Wall mount screw 6 units Install manual
Safety clip 2 units Safety clip screw 2 units
(M4 X 12 mm)
Set protection cushion
4 units
Two mounting screws
for each type of guide spacer
(Top : M6 X 35 mm
Bottom : M6 X 29 mm)
Two top guide spacers Two bottom guide spacers
IMPORTANT SAFETY INSTRUCTIONS
- If you are a professional installer, please read this manual carefully before installing the product.
- If you are a professional installer, please give this manual to the user after installing the product and ensure that the user
also reads the manual carefully and retains it for future reference.
After reading the manual, please keep it handy for future reference.
Warning
The product should be installed by a qualified
professional specified by the retail store.
Product installation by non-qualified personnel is very
dangerous and may cause personal injury.
The product should be installed where its weight
can be fully supported.
If the product is installed on a weak surface, the
product may fall, causing injury.
When moving or replacing the product after
installation, contact a qualified installer specified
by the retail store.
Installation or movement of the product must be carried
out by a skilled professional. If an unqualified person
moves and installs the product, it may cause safety risks.
Do not hang on this product, protect the product
from severe impacts after the installation.
The product may fall and cause injury.
Be sure not to hang the power cable and signal
cable on the back of TV when installing the wall-
mounted TV.
Damaged cables may result in fire, electric shock, or
damage to the product.
Caution
Follow the instructions in this manual to product
properly.
If you do not follow these instructions, the product
may be installed incorrectly and cause serious injury
or the product may become damaged.
To install or adjust the height of the product, two
or more people are needed.
If you try to install or move the product alone, it may
fall and cause injury or the product may become
damaged.
When installing the product, first check that the
wall is strong enough. Use the anchors and
screws provided.
If you use anchors and screws that are not specified
by the manufacturer, they may not hold the weight of
the product, causing safety issues.
When drilling holes into the wall, make sure you
use a drill and drill bit with the specified diameter.
Ensure that you also follow the instructions
regarding the depth of the holes.
Otherwise, the product may be installed incorrectly
and cause safety issues.
Do not clean the product with a wet towel, and do
not place a heater, or humidifier beneath it.
Moisture, steam or heat permeating into this product
may result in fire, electric shock or product damage.
Keep this product away from sprinklers, sensors,
high-tension wires and power sources. Do not
install it in a location where vibrations or impacts
are likely to occur.
Make sure that the power cord is removed from
the outlet before installing the product.
Otherwise, it may cause an electric shock or fire.
Wear safety gloves when installing the product.
Do not use your bare hands.
Otherwise, it may cause personal injury.
Be sure to use the accessory cable provided.
Otherwise, friction between the product and the
wall may cause damage to the connector.
BEFORE INSTALLATION
* Do not use the product for purposes other than mounting a display on the wall.
* When installing/using the wall mount, be cautious of product damage and avoid accidents.
* Install the wall mount according to the installation manual.
* If you have not fully read and understood the installation manual, do not install the product and contact the dealer to
have a specialized installer install the product for you.
* Even if you are not a specialized installer, it is advantageous to have experience in mechanical or construction field in
completely understanding this manual and installing the product.
* Install the product only on a vertical wall.
The manufacturer is not responsible for issue from installing the product on an angled wall or on the ceiling.
* Check that the accessories provided with the product are all included before installing. LG Electronics is not liable for
any damage or loss of accessories after the package has been opened.
* Keep the included accessories out of reach of babies or children as it can cause safety issues including suffocation
from swallowing the parts.
* Make sure screws are tight against the wall, but do not overtighten.
Applying excessive force to screws may damage to the wall, affect the product performance, or cause the product to
become damaged.
* Be careful not to install a TV that exceeds the weight restrictions of the wall mount.
* Be careful with the tools used during installation to prevent accidents or damage.
- Tools you will need - Phillips head + driver (manual or motorized) / 8 mm socket wrench / Level / Drill.
You may also need an Ø 8 mm drill bit for concrete.
