80LB. Hopper Assembly - Figure 1 and Parts List

The Optional

Jet-Action Deflector

LESCO No. 706657

Ref.

No.

Part

No. Description Qty.

1 031168 Screw, 1/4-20 x .75 2

2 060036 Lock Nut, 1/4-20 3

3 061066 Deflector 1

4 060057 Screw, 1/4-20 x 7/8 1

5 061052 Cotter Pin 1

6 061053 Flat Washer 1

7 706254 Mounting Tube 1

8 706305 Handle 1

9 706308 Ring Support 1

Ref.

No.

Part

No. Description Qty.

Ref.

Part

No Description Qty.

1 005530 Nylon Flat Washer, 3/8 1 11 706772 Control Plate Rate 1

2 706696 Screen 1 12 060046 Screen Clip 2

3 030322 Agitator Assembly 1 13 060049 Agitator Arm Assembly 1

4 031167 Hex Cap Screw, 1/4-20, 1.50 4 14 060050 3/8 Retainer Spring Clip 1

5 706895 Lesco Decal, 2-3/8 x 7-1/8 1 15 060057 1/4 -20 x 7/8 Pan Head Mach Screw 1

6 060027 Agitator Shaft Bearing 1 16 700128 Nylon Flat Washer, .26 x .687 x .06 2

7 060033 Flat Washer, 1/4” 4 17 702048 4” x 2” Vinyl Decal 1

8 060036 Nylock Nut, 1/4-20 5 18 704959 Hopper Green 1

9 060043 Control Rate Knob 1 19 705631 Index Washer Hex Screw, #8 x 3/8 2

10 060044 Control Arm Rate 1 20 090006 Decal, USA 1
