Manual

konner-sohnen.com | 6

SPECIFICATIONS

To ensure reliability and increase the engine service life, peak powers may be slightly limited by circuit

breakers.

The optimal operating conditions are ambient temperature of 17-25°C, barometric pressure of 0.1 MPa

(760 mm Hg), and relative humidity of 50-60%. Under these environmental conditions, the generator can

provide maximum performance in terms of the declared specications.

In the event of deviations from these environmental indicators, the generator performance may vary.

Please note that continuous loads exceeding 80% of the generator’s rated power are not recommended in

order to extend its service life.

*LPG operation reduces generator power by 10%.

**Fuel consumption depends on many factors, such as load, fuel quality, season, altitude, technical con-

dition of the generator.

Model KS 2000i S KS 2000iG S

Voltage, V 230

Maximum power, kW 2.0 2.0*

Nominal power, kW 1.8 1.8*

Frequency, Hz 50

Current, A (max.) 8.7 8.7

Outlets 1*16A 1*16A

Engine start manual manual

Fuel tank volume, l 5 5

Working time at 50% load

(gasoline fuel)**, h

6.25 6.25

LED display voltage, frequency, working hours

Noise level Lpa (7m)/Lwa, dB 62/87 62/87

Output 12V, A - -

USB-Outputs 5V/1A, 5V/2.1A -

Engine model KS 100i KS 100i

Engine volume, cm

79.7 79.7

Engine type gasoline, 4 stroke cycle engine LPG/gasoline 4 stroke cycle engine

Engine power, hp 2.5 2.5

Generator parallel socket + +

Crankcase volume, l 0,4 0,4

Power factor, cos φ 1 1

ATS input - -

Dimensions (LxWxH), mm 555х335х540 700х335х540

Lithium battery, Ah - -

Net weight, kg 19 19

Protection class IP23M

Nominal voltage tolerance – max. 5%
