1. Before installing the faucet, flush water supply pipes

thoroughly. Shut off water supply valves.

2. Remove nut, metal washer and rubber washer from faucet.

Do not remove rubber o-ring in bottom of faucet base.

3. Feed tubing through hole in sink or countertop and then insert

faucet assembly into hole.

4. Reinstall the parts onto the threaded shank of the faucet in

the following order: rubber washer, plastic base, metal washer

and nut. Hand-tighten nut.

5. Align faucet and securely hand-tighten the nut to prevent

faucet base from turning when moving operating lever. For

Model series KKFV01SP and KKFV01PP, be sure the control

lever is pointed toward the right side of the sink.

INSTALLATION

REQUIREMENTS

INSTALLATION

INSTRUCTIONS

Tools and Parts

Gather the required tools and parts before starting installation.

Read and follow the instructions provided with any tools listed

here.

Tools needed

■ Adjustable wrench

■ Slip joint pliers

■ #2 Phillips screwdriver

■ Basin wrench (optional)

Tools needed

Remove parts from carton. Check that all parts are included.

All models:

■ Faucet assembly

■ Plastic base

■ ⁵⁄₆₄" (2 mm) Allen wrench

Model series KKFV01SP & KKFV01PP:

■ Weights

■ Check valve assembly

– 2 fiber seals

Location Requirements

IMPORTANT: Observe all governing codes and ordinances.

■ Check location where faucet will be installed. Proper

installation is your responsibility. Make sure you have

everything necessary for correct installation. It is the

responsibility of the installer to comply with installation

specifications and with state and local plumbing codes.

Protect faucet and water lines leading to faucet against

freezing. Damage from freezing is not covered by the warranty.

■ Faucet requires a 1³⁄₈" (3.5 cm) diameter opening in sink or

countertop. If hole is not available for mounting it is

recommended that a qualified installer be contacted to drill the

hole for your installation in a sink deck or countertop.

Thickness of sink or countertop hole must not exceed 1³⁄₄"

(4.4 cm).

■ Hot and cold water supply lines must be available and if they

are not it is recommended that a qualified plumber install the

necessary piping.

■ Faucet hoses are equipped with compression type seals and

do not require sealing compounds to prevent leaking.

■ As with all metal objects, follow proper handling techniques.

■ It is recommended that a qualified plumber/installer install the

faucet. The faucet installation must comply with national and

local plumbing codes and ordinances.

■ The faucet should be examined for damage prior to

installation. Do not install a damaged faucet. Instead, return

the faucet to the dealer from whom you purchased it. Failure

to do so will void the warranty.

A. Rubber washer

B. Metal washer

C. Nut

A. Rubber washer

B. Plastic base

B. Metal washer

C. Nut
