Preparation

How to attach/detach the faceplate

Do not expose the faceplate to direct

sunlight, excessive heat, or humidity. Also

avoid places with too much dust or the

possibility of water splashing.

Keep the faceplate in its casing while

detached.

The faceplate is a precision piece of

equipment and can be damaged by shocks

or jolts.

To prevent deterioration, do not touch the

terminals of the unit and faceplate with

your fingers.

Reset button

How to reset your unit

If this unit fails to operate properly, press the

reset button.

The unit returns to factory

settings when the reset

button is pressed.

Initial settings before operations

Press SRC to enter [STANDBY] mode.

Press the volume knob to enter

[FUNCTION] mode.

Turn the volume knob to select

[INITIAL SET], then press to enter.

Turn the volume knob to make a

selection, then press to confirm.

See table below for selection.

Hold to finish the procedure.

Item Selectable setting (Preset: *)

PRESET TYPE NORMAL/ NORM *: Memorizes one station for each preset button in each band (FM1/ FM2/ FM3/ MW/

LW). ; MIX: Memorizes one station for each preset button regardless of the selected band (FM1/ FM2/

FM3/ MW/ LW).

KEY BEEP ON */ OFF: Activates/deactivates the keypress tone.

RUSSIAN SET ON: Folder name, file name, song title, artist name, album name are displayed in Russian (if applicable). ;

OFF *: Cancels.

P-OFF WAIT Sets the duration when the unit will automatically turns off (while in standby mode) to save the battery.

–––– : Cancels ; 20M *: 20 minutes ; 40M: 40 minutes ; 60M: 60 minutes

BUILT-IN AUX/

BUILTIN AUX

ON1 *: Outputs sound of the connected external component through the car speakers when “AUX” is

selected as the source. ; ON2: Outputs sound from the connected external component when “AUX” is

selected as the source. When you turn on the power, the sound attenuates (to prevent noise when no

external component is connected). Turn the volume knob clockwise to return to the previous volume level. ;

OFF: Disables “AUX” in source selection.

CD READ 1 *: Automatically distinguishes between audio file disc and music CD. ; 2:

Forces to play as a music CD. No

sound can be heard if an audio file disc is played.

SWITCH PREOUT/

SWITCH PRE

REAR */ SUB-W: Selects whether rear speakers or a subwoofer are connected to the line out terminals on

the rear of the unit (through an external amplifier).

SP SELECT OFF */ 5/4/ 6 × 9/6/ OEM: Selects the speaker size for optimum performance.

F/W UP xx.xx YES: Starts upgrading the firmware. ; NO *:

Cancels (upgrading is not activated).

For details on how to update the firmware, see: www.kenwood.com/cs/ce/

[SWITCH PREOUT/ SWITCH PRE] is selectable only with KDC-4051UG/ KDC-4051UR/ KDC-415UA/ KDC-415UR/

KDC-4251URY/ KDC-4551UB/ KDC-455UW/ KDC-4651URY.

EN02-21_KDC-4051UG[E]4.indd 4EN02-21_KDC-4051UG[E]4.indd 4 9/2/10 3:10:44 PM9/2/10 3:10:44 PM
