Manual

Indysll threaded rod to the corresponding holes of AMD bracket

as needed,fixing it with mut facing up.

根据需要将螺杆装入AMD扣具对应孔位内，将隔套内螺

母朝上拧紧固定。

Install the AMD bracdet mount on the cooler base. Fasten the

AMD bracdet with screws.

将AMD支架安装到散热器底座，并用螺丝将其锁紧。

Please remove the original heatsink mount hoder

before further installation.

移除散热器保护膜。

Remove the radiator protective film。

将主板孔位对准散热器定位螺丝，反扣于散热组上。

装入绝缘垫片。

Install insulating washers.

Fix the coolers on the motherboard by fixing the hex nuts

with the wrench.

用开口板手拧紧六角螺母，将散热阻固定到主板上。

The board in place, the fan wire connector is

connected with the mainboard .

主板归位后，将风扇导线接头与主板连接。

CR-901

Apply the thermal grease evenly onto the CPUsurface.

将导热膏均匀涂抺于CPU表面上。
