Manual Intergas Combi Compact ECO RF 24 Central Heating Boiler

Manual

2

Intergas Heating Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic

heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and

promoted by the Heating and Hotwater Industry Council. For more information visit www.centralheating.co.uk. Please ensure that the installer has fully

completed the Benchmark Checklist on the inside back pages of the installation instructions supplied with the product and that you have signed it to say that

you have received a full and clear explanation of its operation. The installer is legally required to complete a commissioning checklist as a means of

complying with the appropriate Building Regulations (England and Wales). All Installations must be notified to Local Aerea Building Control either directly or

through a Competent Persons Scheme. A Building Regulations Compliance Certificate will then be issued to the customer who should, on receipt, write the

Notification Number on the Benchmark Checklist. This product should be serviced regularly to optimise its safety, efficiency and performance. The service

engineer should complete the relevant Service Record on the Benchmark Checklist after each service. The Benchmark cheklist may be required in the

event of any warrranty work and as supporting documentation relating to home improvements in the optional documents section of the Home Information

Pack.

1 OPERATION OF THE APPLIANCE

The purpose of the Intergas Combi Compact ECO RF wall mounted gas fired boiler is to heat water and to supply it to the central

heating (CH) system and the domestic hot water (DHW) taps. Any use deviating from the intended use by the manufacturer may result

in product damage or unsafe situations and will void the warranty.

The heat exchanger comprises of two separate systems for central heating and DHW. The appliance is fitted with a modulating control.

This means that the power is adjusted in line with the required heat, the boiler controller responds to each call for heat from the heating

/DHW system by igniting the burner and monitoring the flame.

1.1 Operation of the central heating

The call for heat arises as a result of the room temperature being lower than the temperature set on the room thermostat. If at that time

the appliance does not have a call for DHW, the appliance comes on in central heating mode. The central heating temperature control

modulates on the basis of the set central heating supply temperature. This means that when the desired central heating supply

temperature is approached the appliance adjusts the power. The pump for the central heating has a post purge period of 1 minute. The

post purge period may be changed if desired. The pump runs automatically for 10 seconds once every 24 hours to prevent blocking.

1.2 Operation of domestic hot water supply

The DHW system is started automatically as soon as more than 2 litres of water per minute are drawn. During delivery of hot tap water

no heat is supplied by the appliance to the central heating system.

For purposes of fast delivery of hot tap water a DHW comfort function has been installed in the controller. This function maintains the

temperature of the heat exchanger. The DHW comfort function has the following settings:

On: ( LED on) The appliance’s DHW comfort function is turned on continuously. In this mode the heat exchanger will be kept on

temperature to assure instant delivery of hot water.

Eco: ( LED on) The appliance’s DHW comfort function is an intelligent system. The appliance will adapt to the pattern of use of hot tap

water. As a result, the temperature of the heat exchanger will only be maintained in periods during which domestic hot water was drawn

on previous days.

Off: (Both LEDs off) The temperature of the heat exchanger is not maintained, as a result of which the delivery of hot tap water takes a

little time. If there is no need for rapid delivery of hot tap water, the DHW comfort function can be switched off.

2 OPERATION AND DISPLAY READ-OUT

Read

-

out

Operation

1

On / off

A

On / Off button

2

CH operation or setting maximum CH temperature

B

DHW / CH button, for setting desired temperature

3

DHW ope

ration or setting DHW temperature

C

-

button

4

Desired temperature of CH or DHW in °C / Ch water pressure (bar) / Fault code/ Time

D

+ button

5

DHW comfort function eco

E

DHW comfort function off / eco / on

6

DHW comfort function on (continuo

us)

F

Service button

7

Operating code

G

Reset button

8

Flashes to indicate fault
