SPECIFICATION:
MODEL NO. : IMC- 3 100S
POWER CONSUMPTION : 600W
RATED VOLTAGE : 230Va.c. 60Hz
CAPACITY : 3L / 6cups
IMPORTANT SAFEGUARD:
1. Read all instructions carefully.
2. Before using the unit, check if the voltage indicated corresponds with the convenience outlet
(230Va.c.).
3. Do not use two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be
replaced with the same type and size or bring the unit to the nearest authorized service
center.
5. Do not place the unit near a gas stove, an electric burner or in a heated oven.
6. Place the unit on a stable surface; keep it away from the edge of the counter to avoid
accidents.
7. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliances by a person
responsible for their safety.
8. Children should be supervised to ensure that they do not play with the appliance.
9. Extreme caution must be exercised when using an appliance containing hot water in the
multi-cooker when boiling.
10. Do not allow the cord to touch the hot surface of the unit.
11. For protection against electric shock, do not immerse the unit including the power base in
water or any other liquid.
12. Always ensure that the lid is closed and do not lift it while the water in the multi-cooker is
boiling. Scalding may occur if the lid is removed during the cooking cycle. Do not touch the
hot surfaces of the rice cooker.
13. Allow the unit to cool down before cleaning.
14. Not intended for outdoor use.
15. Never place the multi-cooker near hot surfaces.
16. No parts are dishwasher safe.
17. Do not exceed into the maximum capacity if the multi-cooker is overfilled, boiling water may
come out due to cooking food below the recommended minimum level or above the
maximum level.
18. Carry or move the multi-cooker only by its handle.
19. In case of malfunctions, please bring the Multi-cooker to the nearest Authorized Imarflex
Service Center.
20. Avoid water spillage into the socket, connector, cord and alike.
21. Multi-cooker body may get very hot, be careful when handling.
22. Use of accessories or equipment not supplied by the manufacturer may cause damage or
malfunctioning of your appliance or result in injuries.
23. Use on a hard, flat level surface only, to avoid interruption of air flow underneath the
appliance.
24. For household use only, not intended for any business purposes.
25. Do not use this unit other than its intended use.
26. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this
appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
DESCRIPTION OF PARTS:
HOW TO USE:
1. Put the rice into the inner pot, measure the desired amount of rice using the measuring cup
supplied with the unit.
2. Wash the rice several times until the water is relatively clear.
3. Measure water on rice for cooking.
I – RICE COOKING
Water Level Ratio for White Rice
White Rice
(Cup)
Inner Pot Water
Capacity (Cup)
Outer Pot Water
Capacity (Cup)
Keep Warm Time
(Minutes)
1
1 ½
1
20
2
2 ½
1
20
3
3 ½
1
20
4
4 ½
1
20
5
5 ½
1
20
6
6 ½
1
20
Note: The amount of water to be added to the inner pot is based on the measuring cup that is
supplied in the unit packaging.
Water Level Ratio for Steaming Brown Rice
Brown Rice
(Cup)
Inner Pot Water
Capacity (Cup)
Outer Pot Water
Capacity (Cup)
Keep Warm Time
(Minutes)
1
2
2
30
2
3
2
30
3
4
2
30
4
5
2
30
5
6
2
30
6
7
2
30
Note: Steaming of frozen foods, add at least 2 cups of water into the outer pot.
4. Adjust the amount of water in the outer pot depending on the type of food and self-
preference.
5. Insert the Stainless-Steel Rack into the unit body.
6. Pour water into the outer pot based on the water level ratio provided in the manual or can
also adjust according to self-preference.
7. Place the inner pot on the top of the rack and put the dome lid on the top of the body.
8. When ready to cook. Plug the unit into the convenience outlet.
Do not plug the unit, until cooking is ready
9. Press down the switch. The “cook” indicator will lights up and the rice will start to cook.
If the switch knob failed to push down, the “warm” indicator will light up, the rice will not be
cooked
10. When it’s done, the switch will pop-up and a click sound will be heard, and the light will turn
to “warm” position.
After the cooking cycle, keep the cover closed for about 20-30 minutes. The rice will be
fluffier
11. Use only the spatula supplied with this unit to avoid scratches.
12. Unplug the unit after every use.
II – FOOD WARMING
1. Place food inside inner pot or leave cooked rice in the inner pot.
2. Leave the unit in “warm” position.
III – STEAMING
1. Adjust the amount of water in the outer pot depending on the type of food and self-
preference.
2. Pour water into the outer pot based on the water level ratio provided in the manual or can
also adjust according to self-preference.
3. Place steamer pan on top of the unit body.
4. Arrange food for steaming inside the steamer pan and cover it.
5. Plug the cord into the convenience outlet and press down the switch to start cooking.
Note: Use the glass lid to cover the steamer since the dome lid will not fit in the steamer.
Others:
Method
Water Ratio and Time Cooking of Outer
Pot
Menu
½ Cup of
Water
1 Cup of
Water
2 Cups of
Water
Steam
15 Minutes
25
Minutes
45 Minutes
Buns, Steam Bread, Egg,
Fish, Meat, Etc.
Stew
25 Minutes
45
Minutes
55 Minutes
Stew 1kg of Chicken or
Mung Beans
