INSTRUCTIONS FOR THE INSTALLER

INSTALLATION

The Purchaser is responsible for the installation of the hob. The Manufacturer does not

accept any responsibility for any damage or loss resulting from incorrect installation,

and as such this will not covered by the Manufacturer’s Guarantee.

The hob may be installed in any worktop which is heat resistant to a temperature of

100° C, and has a thickness of 25 - 45 mm. The dimensions of the insert to be cut out

of the worktop are in shown in Fig. 1.

If the Hob is fitted next to a cabinet on either side, the distance between the Hob and the

cabinet must be at least 15 cm (see Fig. 2); while the distance between the hob and the

rear wall must be at least 5,5 cm.

The distance between the hob and any

other unit or appliance above it (e.g. An ex-

tractor hood) must be no less than 70 cm

(fig.2).

When there is an accessible space between

the built-in hob and the cavity below, a divi-

ding wall made of insulating material should

be inserted (wood or a similar material)

(fig.

3).

Important - The diagram below shows

how the sealant should be applied.

The Hob unit is fitted by attaching the Fixing

Clamps supplied, using the holes at the base of the unit.

Fig. 1

Fig. 2

Fig. 3

accessible space

GB IE

Plan 60 Plan 75

4 a gas 5 a gas

- / si - / si

si si

PL 03/PL 04

PL 73/PL 74

8,75 kW

11,25 kW

636 g/h 818 g/h

220-240/50 220-240/50

BUILT IN HOBS

Burners/hotplates

Type / reference

Flame failure device

Little burner AUS ø 50 mm

Double ring burner QC ø 135 mm

Ultra rapid burner UR ø 110 mm

Semirapid burner SR ø 75 mm

Rapid burner R ø 100 mm

Griddle 174x160 mm

Griddle 229x379

Electric plate ø80 PE

Electric plate ø145 PE

Electric plate 160x265 mm PE

Installed gas Type/Power:

G20 20mbar* (METHANE)

G30 28-30mbar (GPL)

Installation class

Voltage/Frequency V/Hz

Electrical imput power

Electronic ignition

Product dimension WXD (mm)

* Manufacturer setting IE cat. II2H3 + GB cat. II2H3 +

Tab. 1

This appliance has been designed for non-professional, i.e. domestic, use.

GB IE
