Manual

Wiring Diagram

UH3

L N

1 2

RT+ RT-

DS-SB

IN ORDER TO AVOID ANY RISK OF ELECTRIC SHOCK, TURN OFF THE POWER TO THE HEATING

SYSTEM BEFORE COMMENCING INSTALLATION.

1. Separate the front part of the thermostat by placing a small at head

terminal driver into the slots on the bottom face of the thermostat.

2. Terminate the thermostat as shown in the wiring diagram.

3. Screw the back plate securely back onto the wall.

4. Clip the front part of the thermostat onto the back plate and turn the power back on.

The Heatmiser DS-SB is a ush mounted set-back thermostat and is ideal for those

who want a simple but energy ecient temperature control system. The DS-SB

features a set-back function. This function automatically reduces the set temperature

by 4°C when no time clock signal is detected.

The DS-SB thermostat has been designed to work in conjunction with the Heatmiser

UH3 wiring centre and TM4 Programmer, but can also be used as a standalone dial

thermostat.

The Heatmiser DS-SB provides the option to work with a remote temperature sensor.

When a compatible remote sensor is connected, the thermostat will automatically

switch from using it’s internal sensor to use the remote sensor instead. This function

is ideal for controlling bathrooms or when the thermostat needs to be installed in a

dierent area of the building to that being measured and controlled.

Want More Information?

Call our support team on:

+44 (0)1254 669090

Or view technical specications

directly on our website:

www.heatmiser.com

Introduction Installation

Remote Sensor

1 2

Model: DS-SB
