Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

About Your Heat Pump (6100 Series only)

Heat pumps can save money by removing heat

from the outside air—even when the outside

temperature is below freezing—and releasing

that heat indoors.

To get the best performance from your heat pump,

don’t change the room thermostat very often.

Raising the heat setting 2–3 degrees will cause

the Zoneline to use its electric heating elements in

order to reach the new temperature setting quickly.

There is a 3-minute minimum compressor

run time at any setting to prevent short cycling.

The indoor fan motor starts before the compressor

and stops after the compressor cycles off.

When the outdoor temperature is lower than 25°F,

heat is provided by the electric heater in the air

conditioner instead of by the heat pump.

The electric heating elements use much

more electricity than heat pumps and cost

more to operate.

About the controls on your Zoneline. GEAppliances.com

3286307

Temp Control

The temp control is used to maintain the room

temperature. The compressor will cycle on

and off to keep the room at the same level

of comfort.

Press the ▲ pad to raise the temperature.

Press the ▼ pad to lower the temperature.

NOTE: The display shows the set temperature,

not the room temperature.

Sleep

Press to set the air conditioner to run for 8 hours

before it automatically returns to the previous

setting.

When in the cooling mode and the sleep timer

is set, the set temperature will automatically

increase 2°F after the second hour then 1°F

each hour over the next two hours. Also, the

fan speed will change to low. When in the

heating mode, the set temperature will

decrease in the same manner.

To cancel the sleep mode, press the MODE pad

or the SLEEP pad a second time.

Fan, Mode and Operation Control

FAN—Sets the fan operation for HIGH,

LOW or AUTO speed. When set at AUTO,

it automatically switches between LOW

and HIGH as room temperature changes.

MODE—COOL—For cooling

FAN—For fan-only operation

HEAT—For heating

OPERATION—ON/STOP—Turns the unit

on or off. Power remains connected to

the Zoneline. The Freeze/Heat Sentinel

features still function if active.See the

6))>)6)%8)28-2)0 section on page 6.

NOTE: ,)8)14)6%896)(-740%=;-00*0%7,

83-2(-'%8)%4377-&0)92-81%0*92'8-32)8

34)6%8-32'32863083STOP %2(8,)26)78%68

8,)92-8*8,)*0%7,-2+0-+,86)%44)%67;-8,-2

1-298)7'%00*367)6:-')

Quick Heat Recovery

Activates each time the thermostat is switched from

STOP or COOL mode to HEAT mode. Electric heaters

are energized until the thermostat set point

is reached. On heat pump models, the heat pump

operation will resume at the next call for heat.

TEMP CONTROL

FAN, MODE & SLEEP OPERATION
