- Press the stop cylinder against one of the three

sensing stops of the pivoted turret stop (7.6).

- The individual height of each sensing stop can be

adjusted with a screwdriver.

- Push the pointer (7.1) down so that it shows 0" on

the scale (7.3).

b) Setting the milling depth

The desired milling depth can be set either with

the quick depth adjustment or with the ﬁ ne depth

adjustment.

- Quick depth adjustment: Pull the stop cylinder

(7.5) up until the pointer shows the desired mill-

ing depth. Clamp the stop cylinder in this position

with the clamping lever (7.4).

- Fine depth adjustment: Lock the stop cylinder with

the clamping lever (7.4). Set the desired milling

depth by turning the adjusting wheel (7.2) in. Turn

the adjusting wheel to the next mark on the scale

to adjust the milling depth by 0.004" (0.1 mm). One

full turn adjusts the milling depth by aprox. 1/16"

(1 mm). The maximum adjustment range with the

adjusting wheel is 5/16" (8 mm).

c) Increasing the milling depth

Open the rotary knob (7.8) and press the tool down

until the stop cylinder touches the sensing stops.

Working with the router

Always secure the workpiece in such

a manner that it cannot move while being sawed.

The machine must always be held with

both hands by the designated handles.

Always switch the router on ﬁ rst before

bringing the tool into contact with the workpiece!

Always advance the router in the

same direction as the cutting direction of the cutter

(counter-routing)!

You should wear a dust mask for work which

produces dust.

Support of the workpieces

Ensure that your workpieces are

securely ﬁ xed and cannot move during routing.

Otherwise, there is an increased risk of accident.

Use screw clamps or some other suitable devices

to ﬁ x your workpiece.

Sensing stop min. height max. height

Sensing stop /

But ée fixe /

Tope fij o

A 1-1/2" 1-11/16"

B 1-11/16" 2-1/8"

C 2-1/8" 2-5/8"
