Manual

become unsafe and cause serious accident if in-

stalled in benches from other manufacturers or

self-manufactured work benches.

The user is liable for damages and

injuries due to incorrect usage.

Electrical connection

The network voltage must conform to the voltage

indicated on the rating plate. A 16 A safety fuse (for

120 V) or a corresponding protective circuit-breaker

is required.

See the ﬁ gure aside for connection and disconnec-

tion of the power cable.

Always switch the machine off before

connecting or disconnecting the power cable!

Extension cable

If an extension cable is required, it must have a suf-

ﬁ cient cross-section so as to prevent an excessive

drop in voltage or overheating. An excessive drop in

voltage reduces the output and can lead to failure

of the motor. The table shows you the correct cable

diameter as a function of the cable length for the

router OF 1010 EQ. Use only U.L. and CSA listed

extension cables. Never use two extension cables

together. Instead, use one long one.

Note: The lower the AWG number, the stronger the

cable.

Switching the machine on and off

Keep the machine steady during

switching and during use by holding the handle (3.2)

and the additional handle (3.1) with both hands.

The switch (3.4) is used to switch the tool on and off.

For continuous operation the switch can be locked

by means of the button on the side (3.3). The switch

can be unlocked by pressing again.

After the machine has been switched

off, the milling cutter will still rotate for a time. Take

care that parts of your body do not come into contact

with the milling cutter while it is still rotating!

Electronics

Do not work with the OF 1010 EQ if the

electronic control is defective since this may lead to

excessive speeds. A defect in the electronic control

is indicated by the absence of a smooth run-up, a

higher noise level at idle or the fact that no speed

control is possible.

3.2

3.1

3.3

3.4

Total Extension Cord

Lenght (feed)

25 50 100 150

Cord size (AWG) 18 16 14 12
