Instruction for the User

Hob burners control knobs

The hob burners control knobs are situated on the hob

lateral panel. The symbols on the knobs mean that :

l there is no gas supply

there is maximum gas supply

there is minimum gas supply

Lighting the burners

For easier lighting, proceed before putting a pan on

the pan support.

l To light a burner, push in the relevant control

knob and turn it anti-clockwise to "maximum"

position.

l Upon ignition, keep the knob pushed down for

about 5 seconds. This will allow the

"thermocouple" (Fig. 1 lett. D) to be heated and

the safety device to be switched off, otherwise

the gas supply would be interrupted.Then,

check the flame is regular and adjust it as

required.

l If you cannot light the flame even after several

attempts, check the "cap" (Fig. 1 lett. A) and

the "crown" (Fig. 1 lett. B) are in the correct

position.

l To put the flame out, turn the knob to the

symbol l.

Always turn the flame down or put it out

before taking the pans off the burner.

Using the hob correctly

To ensure maximum burner efficiency, it is strongly

recommended that you use only pots and pans with a flat

bottom fitting the size of the burner used, so that flame will

not spread beyond the bottom of the vessel (see the table

beside).

It is also advisable, as soon as a liquid starts boiling, to

turn down the flame so that it will barely keep the liquid

simmering.

Carefully supervise cookings with fats or oil,

since these types of foodstuff can result in a

fire, if over-heated.

Burner minimum maximum

diameter diameter

Big (rapid) 180 mm. 260 mm.

Medium (semirapid) 120 mm. 220 mm.

Small (Auxiliary) 80 mm. 160 mm.

Fig. 1

FO 0204

A - Burner cap

B - Burner crown

C - Ignition candle

D - Thermocouple

For the user

For Your Safety 12

Instruction for the User 13

Cleaning and Maintenance 14

Contents

For the installer

Technical Data 15

Gas connection 15

Electrical Connection 16

Adaptation to different types of gas 17

Building in 18
