Manual

• Loose and incorrect mains plug and sock-

et connections can make the terminal be-

come too hot.

• A qualified electrician must install the

clamping connections correctly.

• Use a strain relief clamp on cable.

• Use the correct mains connection cable

and replace the damaged mains cable

with applicable cable. Speak to your local

Service Force Centre.

• The appliance must have the electrical in-

stallation which lets you disconnect the

appliance from the mains at all poles with

a contact opening width of minimum 3

mm.

• You must have correct isolation devices:

line protecting cut-outs, fuses (screw type

fuses removed from the holder), ground

leakage trips and contactors.

Disposal of the appliance

• To prevent the risk of physical injury or

damage

– Disconnect the appliance from the pow-

er supply.

– Cut off the mains cable where it con-

nects with the appliance and discard it.

– Flat the external gas pipes if there are

fitted.

– Speak to your local authorised facilities

for disposal of your appliance.

INSTALLATION

Warning! The following instructions

about installation, connection and

maintenance must be carried out by

qualified personnel in compliance with

standards and local regulations in force.

Gas Connection

Choose fixed connections or use a flexible

pipe in stainless steel in compliance with the

regulation in force. If you use flexible metallic

pipes, be careful they do not come in touch

with mobile parts or they are not squeezed.

Also be careful when the hob is put together

with an oven.

Important! Make sure that the gas supply

pressure of the appliance obeys the

recommended values. The adjustable

connection is fixed to the comprehensive

ramp by means of a threaded nut G 1/2".

Screw the parts without force, adjust the

connection in the necessary direction and

tighten everything.

1 End of shaft with nut

2 Washer (additional washer is only for

Slovenia and Turkey)

3 Elbow

4 Rubber pipe holder for liquid gas (only for

Slovenia and Turkey)

Rigid connection:

Carry out connection by using metal rigid

pipes (copper with mechanical end).

"Flexible" connection with mechanical

end:

–

Natural gas : connection carry out with a

flexible pipe with mechanical end which is

screwed directly on the elbow finishing the

slope of the appliance.

4 electrolux
