Manual

Note: Most newer PC cases include a CPU cutout to allow access to the bottom of

the motherboard. If your case does not include a cutout, you will need to remove

your motherboard from the case before installation.

Remarque : la plupart des nouveaux boîtiers de PC comportent un accès facilité au

processeur qui permet d'accéder à la base de la carte mère. Si aucun accès n'est

prévu sur votre boîtier, vous devrez retirer votre carte mère du boîtier avant de

procéder à l'installation.

Hinweis: Bei neueren PC-Gehäusen gibt in der Regel eine CPU-Önung Zugang zur

Unterseite der Hauptplatine. Falls Ihr Gehäuse keine derartige Önung aufweist,

müssen Sie vor der Installation die Hauptplatine ausbauen.

Nota: La mayoría de las carcasas de las nuevas PC incluyen una puerta trasera para el

CPU a ﬁn de permitir el acceso a la parte inferior del motherboard. Si su carcasa no

tiene esta entrada, deberá retirar el motherboard de la carcasa antes de la instalación.

Примечание. На большинстве современных корпусов ПК имеется прорезь для предоставления

доступа к нижней части материнской платы. Если на вашем корпусе нет такой прорези, то перед

установкой необходимо удалить материнскую плату из корпуса.

注：大部分型号较新的PC机箱都配有CPU散热器更换口，可以在不移动主板的情况直接更换CPU散热

器，如果您的机箱未预留此空间，需要在水冷安装前取下主板。

Included Hardware

Highlighted parts for Intel installation only • Les sections en surbrillance concernent

uniquement l'installation Intel • Die markierten Passagen beziehen sich nur auf die Intel

Componentes de instalación solamente para Intel • Части, выделенные цветом, только для установки Intel

突出显示的部分仅限Intel安装

Note: The H80i v2 comes with Intel mounting bracket pre-installed on the pump for quick installation.

Remarque : pour une installation plus rapide, le support de ﬁxation Intel est déjà monté sur la pompe du dissipateur H80i v2.

Hinweis: Beim Hochleistungsprozessorkühler H80i v2 ist die Intel-Montagehalterung bereits auf der Pumpe vorinstalliert und

ermöglicht so eine besonders schnelle Montage.

Nota: El H80i v2 viene con un soporte de montaje Intel preinstalado en la bomba para una instalación rápida.

Примечание. H80i v2 поставляется с установленным на насос монтажным кронштейном Intel для быстрой установки.

注：H80i v2的泵机上预装了Intel安装支架，可进行快速安装。

x1 INTEL MOUNTING BRACKET

(PRE-INSTALLED)

x2 SP120L FANS

x1 INTEL BACKPLATE

x8 LONG FAN SCREWS

x4 THUMBSCREWS

x4 LGA 2011 STANDOFF

x4 LGA 115X / 1366 STANDOFF

x8 WASHER

x4 AMD BLACK STANDOFF

x1 AMD MOUNTING

BRACKET
