Manual

English

GREAT BRITAIN • customer service

tel: 08545 300 9799 e-mail: [email protected] internet: www.clasohlson.com/uk

Ver. 20131031

Smoke detector

Art. no. 32-1988, 32-3381, 32-3382,

32-3383

Placing of smoke

detector

Do not put asmoke detector in the

following places

• Do not place asmoke detector in akitchen

with poor ventilation. Smoke and fumes from

thepreparation of food and baking can trigger

thealarm.

• Do not place smoke detector near fans or

ventilation conduits. Smoke could drift in their

direction instead of toward thesmoke detector.

• Do not place asmoke detector in agarage.

A car’s exhaust may trigger analarm.

• Do not place asmoke detector in very damp

spaces or aspace exposed to broad temperature

variations. A smoke detector should not be placed

in anarea where thetemperature is below 5 °C or

above 40 °C.

A smoke detector should not be painted.

Assembly

Test and care

1. Test thesmoke detector at least once every

month, and preferably once per week, e.g.,

when you house clean.

2. Always test thesmoke detector after returning

from holidays or after being away for aprolonged

period. The smoke detector can be tested with

thetest button or by blowing alittle smoke

toward thesmoke detector.

3. The smoke detector sounds as long as thetest

button is pressed down or as long as there is

smoke in it.

4. Make sure thebattery is correctly positioned. Replace

battery if thesmoke detector makes no noise.

5. Below thetest button is ared diode that blinks

1–2 times per minute. It shows that thesmoke

detector is working.

6. Wipe thesurface of thesmoke detector with

amoist cloth when needed. When cleaning

house, thesmoke detector may be vacuumed

slightly as you do house cleaning.

Switching off thealarm sound

(model 32-3383)

When asmoke detector is placed in, say, akitchen

thealarm may be sometimes set off unintentionally.

The alarm sound can then be shut off for about ten

minutes by pressing on thetest button. Two signals

are heard when thesmoke detector returns again to

its normal state.

Changing batteries

A battery lasts for about one year. About one month

before thebattery is completely discharged, thesmoke

detector will start to emit short signals at about

one-half minute intervals. It is then time to replace

thebattery. Once this is done thedetector will start

working again.

Battery: 9 V standard or alkaline battery, e.g.,

Duracell MN 1604, Eveready no. 522, 1222 or 216,

Gold Peak 1604 P.

Always test smoke thedetector after replacing

thebattery.

Full

battery

When

sound

heard

Replace

battery

Control

lamp

Blinks

1–2 times/

min

Blinks

without

interrup-

tion

Alarm signal +

blinks once per

minute

Alarm

signal

Interrupted

signal

Alarm

signal

Blinks + Alarm

signal once/min

Guarantee

The smoke detector has a5-year guarantee

calculated from day of delivery. The guarantee covers

material and manufacturing ﬂaws and is limited to

new for old or repairs. The guarantee is valid provided

only that theinstructions are followed. Return

adefective smoke detector to vendor or importer

(address below) with indication of defect and battery.

Announcement from (Finnish)

Radiation Safety Centre

(Does not apply to optical smoke detector model

32-3382).

This smoke detector contains asmall amount of

radioactive substance – americium 241.

The Finnish Radiation Safety Centre has investigated

and approved theradiation safety of this type of

smoke detector. In said test, normal use of thesmoke

detector does not expose humans to doses harmful

to thehealth.

Normal use entails:

• Correct choice of where to place thedetector.

• Smoke detector is used in frequented places.

• Proper care of smoke detector, e.g., instructions

for replacing battery and for cleaning are followed.

• The smoke detector must not be used by

children. The smoke detector may be disposed of

with thehousehold rubbish.

• The approval number of theFinnish Radiation

Safety Centre and theimporters address are on

thelabel on thesmoke detector.

Bedroom

Cellar

Place in ceiling 50 cm

from wall

On wall 15–20 cm

from ceiling

• The smoke detector should bee placed in

theceiling near bedrooms

• If thebedrooms are in different parts of

thedwelling, asmoke detector should be placed

in each room.

• In abuilding with several ﬂats there should be

asmoke detector in every ﬂat.

• Make sure thesound from thesmoke detector is

distinctly heard.

• The earlier your family is warned thegreater

thechance of saving family members and

salvaging property.

1. Remove

thebottom plate

by turning it

slightly.

2. Insert battery

and attach

theconnecting

wires.

3. Press thetest

button and hold

down afew

seconds to test

thealarm sound.

4. Next check that thered light diode is blinking afew

times per minute.

5. Attach thebottom plate to theceiling with

theenclosed screws. Then screw thesmoke

detector tightly to thebottom plate.

Connecting function

Pull cable (e.g. oval wire SKF 2×0.75 mm²) between

thesmoke detectors that shall be connected.

The smoke detectors should be connected in parallel.
