Safety Precautions

WARNING!

Compressed air can be dangerous.

Follow these safety instructions carefully.

• Never direct a jet of compressed air at people or animals, or spray

paint towards people or animals.

• Use appropriate protective equipment, such as Clarke safety-

goggles or glasses, dust masks, ear defenders etc. when using

compressed air tools.

• Air compressors work at high pressure. Inspect equipment and hoses

regularly, checking for any damage or leaks. Have any damage

properly repaired before using the machine again.

• Do not operate the compressor with any guards removed.

• Do not adjust or tamper with the safety valve in any way. The maximum

working pressure (115 psi - approximately 8 bar) is clearly marked on

the compressor and air receiver.

• The compressor will become hot during operation. Do not touch the

cylinder head or discharge pipe while the compressor is in use.

• Always close the air outlet valve and release any pressure from the air

hose (by operating the tool briefly) before disconnecting any hoses

or tools.

When paint spraying:

• Always wear a suitably approved breathing mask when paint

spraying, to protect against inhalation of paint spray or fumes.

An airfeed mask may be required when spraying some types of paint.

If in doubt, check the paint manufacturers instructions.

• Make sure there is adequate ventilation. Do not spray in confined or

enclosed areas.

• Many paints are flammable. Do not smoke while spraying or preparing

paints, or spray near a naked flame or heat source.

- 4 -

-17 -

PARTS LIST (Compressor)

No Description Qty No Description Qty

1 Screw 4 28 Hose Adapter 1

2 Compressor Head 1 31 Hose 1

3 Gasket 1 33 Pressure Gauge 1

4 Valve 1 34 Disk 1

5 Valve Plate 1 35 Screw 1

6 Gasket 1 36 Filter retainer 1

7 Screw 1 37 Air Filter 1

8 Piston Segment 1 38 Motor 1

9 Con-Rod 1 39 Bearing 1

10 Screw 4 40 On/Off Press Rel Valve 1

11 Crankcase 1 41 Pressure Gauge 1

12 Eccentric Shaft 1 42 Valve Block 1

13 Screw 4 43 Hose adapter 1

14 Base Plate 1 44 Pressure Rel Valve 1

15 Screw 1 45 Olive 1

17 Fan 1 46 Hose Connector 1

18 Motor Shaft 1 47 Hose 1

19 Capacitor 1 48 Hose Clamp 1

20 Plastic Cover 1 49 Hose 1

21 Bayonet Conn Nut 1 50 Power Cable 1

22 Tap 1 51 Cable 1

25 Pressure Regulator Assy 1
