Manual

FEATURES

The pumps are of rugged and durable construction, designed for long lasting continuous

operation, and the motor is provided with a built in overload protector.

For your information, the chart on page 7 illustrates the flow rate at various heads.

(HEAD is the distance, or height, from the pump outlet to the highest point of discharge)

All models are designed for pumping CLEAN WATER ONLY and will pump down to a

water level of 5mm.

Automatic Pumps, i.e. those fitted with a Float Switch, denoted by an ‘A’ suffix to their

model number, are suitable for permanent or semi-permanent installations, eg. installations

where it is necessary to maintain a water at a particular level.

As the water level rises, the switch will float, and start the pump. As the water level falls,

so will the float switch, until it stops the pump.

Float switches are factory set to provide the correct ON-OFF switching mode, however,

you can adjust the level at which the pump cuts out by sliding the float switch cable, in its

clip attached to the handle, to either shorten or lengthen it as the case may be. The

shorter it is, the earlier it will cut out and therefore, the deeper will be the water at this

point.

INSTALLATION

An Elbow Outlet is provided with a 1-1/4”BSP

thread at either end as shown in the diagram

opposite. Ensure the end provided with an O-Ring

is screwed into the pump outlet. Screwed into the

other end of the elbow, is a multi hose connector

capable of accepting 1”, 3/4” 0r 1/2” hose. Simply

attach a suitable hose to your preferred connector

with a worm drive clip.

If the pump is to be used for drainage purposes, or

in situations that demand maximum efficiency, we

strongly recommend that you connect a 1” dia. hose

Download manual in English (PDF, 2.14 MB)
