WARNING:
A
s with all machinery, there are certain hazards involved with their operation
and use. Exercising respect and caution will considerably lessen the risk of
personal injury. However, if normal safety precautions are overlooked or
ignored, personal injury to the operator or damage to property, may result.
1. Never use these pumps for pumping flammable liquids such as petrol.
2. In pumping corrosive materials, extreme caution should he exercised. Provide
safety guards, ventilation, and drains to protect people and property in case
of a leak in the pump.
Handling instructions from the manufacturer(s) of the liquids being pumped
should be closely followed.
3. Before starting the pump, follow all of the instructions in this manual and any
supplemental instructions supplied with the pump.
4. Any person operating this pump and its’ power unit should be fully aware of
its safe operation before they start using it.
5. Never operate an engine driven unit in an explosive atmosphere, near
combustible materials, or where insufficient ventilation exists unless specific
provisions have been made regarding the power unit so as to prevent possible
injury and damage. Be certain any other power unit is safe for the area in
which it is to be operated.
6. Always be sure that the unit is on a secure footing and keep the immediate
pump and power unit area free of all unauthorized personnel. If the pump is
sitting beside a pit, be sure it is well anchored so that it does not fall in.
7. Never operate the unit with any guards removed.
8. Do not overtighten the drain or filter plugs. Excessive force may damage the
threads or the pump body.
9. With engine driven pumps:
a. Observe all safety precautions for the handling of fuel.
b. Never refuel the engine while running, and care should be exercised so
that no fuel is spilled on a hot engine.
10. Before working on this pump make sure that the power unit cannot
inadvertently be started.
11. Be sure that the power unit, pump, wiring and piping installations are suitable for the
liquid being pumped, and comply with all applicable codes and regulations.
12. Use at least 300mm of flexible hose to make plumbing connections to the pump
body. Rigid piping may put stresses on the pump, causing damage. If the rigid
piping must be used, properly support it so as to eliminate stresses on the pump.
13. Use replacement parts supplied by the manufacturer only.
14. Do not run the pump dry. Always fill the pump body with the liquid to be
SAFETY PRECAUTIONS
4
PARTS LIST - CRD2
9
No. Description Q’ty Part No.
1 Casing 1 503-001
2 Casing Cover 1 501-004
3 Impeller 1 501-009
4 Inner Casing 1 501-011
5 Bend 1 501-019
6 Valve Case 1 501-013
7 Mechanical Seal 1 501-010
8 Packing, Casing 1 501-002
9 Packing, Inner Casing 1 501-012
10 Packing, Bend 1 501-020
11 Check Valve 1 501-015
12 Plug 2 501-021
13 Packing, Plug 2 501-022
14 Bolt M8x50 4 501-005
15 Spring Washer 8 4 501-007
16 Plain Washer 8 4 501-008
17 Seal Packing 4 501-006
18 Frame 1 501-030rd2
19 Hex.bolt M10x30 4 501-003
20 Hex.bolt M8x25 4 501-014
21 Hex.bolt M8x25 3 501-014
22 Hex.bolt M8x40 4 501-023
23 Frange Nut 8 4 501-024
24 Packing, Coupling 2 501-017
25 Hose Coupling 2 501-018p
26 Hose Coupling Handle 2 501-016p
27 Hose Band 3 501-028
28 Strainer 1 505-029
For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
SERVICE: ........................ Service@clarkeinternational.com
