Thank you for purchasing this CLARKE 13mm Hammer Drill which is designed for

lighter duty, DIY use only.

Please read this booklet thoroughly. Your Clarke Hammer Drill will give excellent

service if it is used carefully and in accordance with the following advice and

recommendations. Never use excessive force and as with all tools, it should be

treated with care and respect.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt as proof of purchase.

This guarantee is invalid if the product is found to have been abused or tampered

with in any way, or not used for the purpose for which it was intended.

Faulty goods should be returned to their place of purchase, no product can be

returned to us without prior permission. This guarantee does not effect your

statutory rights.

TECHNICAL DATA

CHD490 CHD810

Motor 230V 50Hz 230V 50Hz

Power Input 500Watts 810Watts

Chuck Capacity 13mm 13mm

Speed Range 2,900RPM 10 - 2,900RPM

Sound Pressure Level 96.8dB(A) 94.5dB(A)

Sound Power Level 109.8dB(A) 107.5dB(A)

Vibration Level 24.1m/s

5.2m/s

Weight 2.5kg 2.4kg

Part No. 6480100 6480110

Please note that the details and specifications contained herein, are correct at the time of going to

print. However, CLARKE International reserve the right to change specifications at any time without

prior notice. Always consult the machine’s data plate

PARTS LIST AND DIAGRAM

Please contact your nearest dealer,

or CLARKE International, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400

PARTS & SERVICE FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]

Spare Parts and Service

No. Description Part No.

CHD490 CHD810

1 Chuck GRCHD49001 GRCHD81001

- Chuck securing screw GRCHD49002 GRCHD81002

2 Chuck Key GRCHD49003 GRCHD81003

3 Auxiliary Handle Complete GRCHD49004 GRCHD81004

4 Depth Gauge GRCHD49005 GRCHD81005

Download manual in English (PDF, 0.79 MB)
