Thank you for purchasing this CLARKE Water Pump, which is a general purpose

pump, suitable for a variety of applications involving the transfer of clean, cold

water ONLY.

The CEB101 differs from the TAM 100 model in that it has a brass body designed for

longer life, and an increased resistance to corrosion.

To help ensure long, trouble free performance and the protection afforded by

the warranty, please follow carefully all the instructions and recommendations

given in this booklet.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt as proof of purchase.

This guarantee is invalid if the product is found to have been abused or tampered

with in any way, or not used for the purpose for which it was intended.

Faulty goods should be returned to their place of purchase. No product can be

returned to us without prior permission. This guarantee does not effect your

statutory rights.

SAFETY PRECAUTIONS

1. Ensure the pump is installed in a horizontal position with the outlet facing

vertically upwards, and that it is firmly anchored via its fixing screws.

2. Ensure there is an adequate air flow around the pump. DO NOT mount it in an

enclosed atmosphere.

3. Ensure all water pipes - supply or discharge, are adequately supported where

necessary, so as not to put a strain on the pump connections.

4. DO NOT allow the pump to run dry, as this will cause serious damage to the

pump seals.

5. Ensure the inlet to the pump is completely unrestricted.

6. Ensure the pump is protected from the elements, neither the motor nor the

electrical terminal box is intended to be waterproof.

7. Ensure that all pipes are protected against damage where necessary, and

that they are suitably lagged to avoid the possibility of freezing during cold

weather.

SPECIFICATIONS

TAM100 CEB101

Motor 230V 50Hz 1ph 230V 50Hz 1ph

Power 0.5HP 0.5HP

Speed 2800 RPM 2800 RPM

Max. Head 44M 40M

Max. Lift (Suction) 8M 8M

Bore Size 1”BSP 1”BSP

Max. Output 40 litres/min 38 litres/min

Weight 5.8kg 6.25kg

Part Number 7320035 7230320

NOTE: As the pumping head is increased, so the flow rate of water will decrease.

ACCESSORIES

1” Foot Valve Filter 7950561

1” BSP Spigot Hose Connector 7950210

1” I.D. Reinforced Hose for suction and delivery. 7955010

1” I.D. Layflat Hose for delivery only. 7955110

Please contact your nearest dealer, or

CLARKE International, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400

PARTS & SERVICE FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]

Please note that the details and specifications contained herein, are correct at the time of going to

print. However, CLARKE International reserve the right to change specifications at any time without

prior notice. Always consult the pump’s data plate

PARTS & SERVICE
