Manual

Thank you for purchasing this CLARKE Circular Saw, designed for cutting wood ONLY.

Before attempting to use the machine, please read this manual thoroughly and follow the

instructions carefully. In doing so you will ensure the safety of yourself and that of others

around you, and you can look forward to the saw giving you long and satisfactory service.

Guarantee

This product is guaranteed against faulty manufacture for a period of 12 months from the

date of purchase. Please keep your receipt which will be required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or tampered with in

any way, or not used for the purpose for which it was intended.

Faulty goods should be returned to their place of purchase, no product can be returned to

us without prior permission.

This guarantee does not effect your statutory rights.

Specifications

Mains Supply ..................................................................................... 230V 50Hz 1ph

Power Rating .................................................................................... 1300W

Fuse Rating ....................................................................................... 13amp

No Load Speed ................................................................................ 4,800 RPM

Guaranteed Sound Power Level (Under Load) .......................... 108.6dBL

Weight ............................................................................................... 6kg

Cutting Capacity @ 90º .................................................................. 60mm

Cutting Capacity @ 45º .................................................................. 45mm

Blade/Bore Diameter/Type ............................................................ 185/20mm/TCT

Dimensions ........................................................................................ 353x250x290mm

Part Number ..................................................................................... 6462040

Please note that the details and specifications contained herein, are correct at the time of going to print. However,

CLARKE International reserve the right to change specifications at any time without prior notice.

Declared vibration emission value in accordance with

EN12096

Measured vibration emission value -

<2.5m/s

Uncertainty value -

0.99m/s

Highest measured reading in a single plane 4.56m/s

Values determined according to EN28622-1

This product Confirms to 98/37/EEC Regulations

Parts List

PARTS & SERVICE TEL: 020 8988 7400

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]

No. Description Part No. No. Description Part No.

1 Screw TMCCCS201

2 Back Cover TMCCCS202

3 Screw TMCCCS203

4 Plate TMCCCS204

5 Brush Holder TMCCCS205

6 Carbon Brush TMCCCS206

7 Carbon Brush Cap TMCCCS207

8 Handle TMCCCS208

9 Housing TMCCCS209

10 Stator TMCCCS210

11 Screw TMCCCS211

12 End Plate TMCCCS212

13 Bearing Sleeve TMCCCS213

14 Bearing 609 TMCCCS214

15 Armature TMCCCS215

16 Bearing TMCCCS216

17 Case TMCCCS217

18 Spring TMCCCS218

19 Self-locking Bolt TMCCCS219

20 Button TMCCCS220

21 Upper Blade Guard TMCCCS221

22 Screw TMCCCS222

23 Bracket TMCCCS223

24 Brace TMCCCS224

25 Washer TMCCCS225

26 Nut TMCCCS226

27 Ring TMCCCS227

28 Bevel Locking Lever TMCCCS228

29 Washer TMCCCS229

30 Screw TMCCCS230

31 Long Rivet TMCCCS231

32 Spindle TMCCCS232

33 Screw TMCCCS233

34 Base TMCCCS234

35 Screw TMCCCS235

36 Depth Plate w/scale TMCCCS236

37 Rivet TMCCCS237

38 Handle TMCCCS238

39 Screw TMCCCS239

40 Cord Clamp TMCCCS240

41 Screw TMCCCS241

42 Rubber Handle TMCCCS242

43 Cable Gland/protector TMCCCS243

44 Capacitor TMCCCS244

45 Switch TMCCCS245

46 Handle Cover TMCCCS246

47 Screw TMCCCS247

48 Locking Lever TMCCCS248

49 Ring TMCCCS249

50 Depth Locking Lever TMCCCS250

51 Washer TMCCCS251

52 Screw TMCCCS252

53 Cable complete TMCCCS253

54 Needle Bearing TMCCCS254

55 Gear TMCCCS255

56 Woodruff Key TMCCCS256

57 Spindle TMCCCS257

58 Round Plate TMCCCS258

59 Bearing TMCCCS259

60 Front Cover TMCCCS260

61 Screw TMCCCS261

62 Riving Knife Bracket TMCCCS262

63 Nut TMCCCS263

64 Riving Knife TMCCCS264

65 Screw TMCCCS265

66 Rod TMCCCS266

67 Rivet TMCCCS267

68 Plastic Ring TMCCCS268

69 Lower Blade Guard TMCCCS269

70 Lever TMCCCS270

71 Screw TMCCCS271

72 Ring TMCCCS272

73 Inner Flange TMCCCS273

74 Blade See Dealer

75 Outer Flange TMCCCS275

76 Screw TMCCCS276
