Manual

Notes:

- Choose the mounting location where the

unit will not interfere with the normal driving

function of the driver.

- Before finally installing the unit, connect

the wiring temporarily and make sure it is all

connected up properly and the unit and the

system work properly.

- Use only the parts included with the unit to

ensure proper installation. The use of

unauthorized parts can cause malfunctions.

- Consult with your nearest dealer if

installation requires the drilling of holes or

other modifications of the vehicle.

- Install the unit where it does not get in the

driver's way and cannot injure the

passenger if there is a sudden stop, like an

emergency stop.

- If installation ang e exceeds 30°from

horizontal, the unit might not give its

optimum performance

- Avoid installing the unit where it would be

subject to high temperature, such as from

direct sunlight, or from hot air, from the

heater, or where it would be subject to dust,

dirt or excessive vibration.

Din Front/Rear-Mount

This unit can be properly installed either

from 'Front' (conventional DIN Front-mount)

or 'Rear' (DIN Rear-mount installation,

utilizing threaded screw Holes at the sides

of the unit chassis). For details, refer to the

following illustrated installation methods.

Installing the unit

Be sure you test all connections first, and

then follow these steps to install the unit.

1. Make sure the ignition is turned off, and

then disconnect the cable from the vehicle

battery's negative (-) terminal.

5. The two supplied keys release tabs

inside the unit's sleeve so you can remove

it. Insert the keys as far as they will go (with

the notches facing up) into the appropriate

slots at the middle left and right sides of the

unit. Then slide the sleeve off the back of

the unit.

2. Disconnect the wire harness and the

antenna.

3. Press the button on the front panel and

remove the control panel (For details, refer

to 'using the detachable front panel').

4. Lift the top of the outer trim ring then pull

it out to remove it.

Installation Opening

This unit can be installed in any dashboard

having an opening as shown below:

Installation

1. DIN FRONT-MOUNT (Method A)

53mm

182mm

Take Out Screw Before Installation

Before install the unit, please remove the

two screws.

Download manual in English (PDF, 0.44 MB)
