Manual Braun BP4900 ExactFit 3 Blood Pressure Monitor

Manual

4

5

• Do not wrap the cu over jacket or sweater sleeve or measurement cannot be done.

• Remove tight-tting clothing from your left arm.

• Do not in any way twist the arm cu.

• Do not inate the monitor’s cu when it is not wrapped around the arm.

• Do not attempt to disassemble or change any parts of the monitor including the cu.

• Do not drop the product or put it through strong impact.

• The device is not supposed to be used if your arm has any wound or injury.

Applying the arm au

1. Slide the end of arm cu furthest from the tube through the metal ring to a loop.

The smooth cloth should be on the inside of the cu.

2. If the cu is located correctly, the velcro will be on the outside of the cu and the metal ring

will not touch the skin. (Fig. 4)

3. Put your left arm through the cu loop. The bottom of the cu should be approximately

(2~3 cm) above elbow. The tube should lie over the brachial artery on the inside of the arm.

(Fig. 5)

4. Pull the cu so that the top and bottom edges are tightened around your arm. (Fig. 6)

5. When the cu is positioned properly, press the Velcro rmly against the pile side of the cu.

6. This cu is suitable for use if the <<index>> mark falls within the <<ok range>> marked by

two arrows when the cu is tightened around your arm. (Fig. 7)

7. Sit on a chair and place your arm on the table so that the cu is at the same level as your

heart. (Fig. 8)

Index

Fig. 5

Main

arteries

Left arm

Fig. 4

Pile side material

Velcro

Smooth

cloth

Metal ring

Fig. 6

Fig. 7

Adult cuff

23 ~ 43 cm

Index

OKOK

Fig. 8

• To ensure accurate measuring results, carefully read the complete use instructions.

• This product is intended for household use only. Keep product and batteries away

from children.

• People suering from cardiac arrhythmia, vascular constriction, arteriosclerosis in

extremities, diabetes or users of cardiac pacemakers should consult their doctor

before measuring their blood pressure themselves, since deviations in blood pressure

values may occur in such cases.

• If you are under medical treatment or taking any medication, please consult your

doctor rst.

• The use of this blood pressure monitor is not intended as a substitute for consultation

with your doctor.

Product description

1. Start/stop button

2. Memory button

M

3. Average button

4. Set button

5. Mode button

6. Battery compartment cover

7. Hose port

8. Connector

9. Hose

10. Arm cu

11. 4X AA alkaline batteries (1,5v)

12. LCD display

Inserting batteries

• Remove the battery compartment cover at the bottom of the

unit and insert 4 AA LR6 ALKALINE batteries with correct polarity

(see symbol in the battery compartment).

• Note: Always re-set Date and Time after replacing new batteries

to make sure the measurement results are stored with correct

date and time.

• Only discard empty batteries. They should not be

disposed of in the household waste, but at appropriate

collection sites or at your retailer.

Key rules for accurate blood pressure

measurement

• Always take readings at the same time of day, ideally in the morning and evening,

under the same conditions.

• Do not measure within 30 minutes after smoking or consuming coee or tea.

• Take o wrist watch and jewelry before tting the cu on the measuring arm.

• While taking a measurement, sit down, relax, keep still, and do not move or speak.

• Wrap the cu snugly around your arm. The cu must be at heart level.

• Do not vibrate the unit during measurement, or the proper measurement

will not be achieved.

• Perform measurement quietly in a relaxed position.

• Sit in a chair with your feet at on the oor.

Fig. 2

Fig. 3

Rating
