Manual

After-sales service

Before contacting After-Sales

Service:

See if you can solve the problem

yourself with the help of

theTroubleshooting guide”).

Switch off the hood for a few

minutes and re-start it to see if

the problem has cleared itself.

If the malfunction persists, call

After-Sales Service.

Specify:

•

The nature of the problem.

•

The model.

•

The service code (number

below the word SERVICE on the

rating plate inside the hood

behind the grease filter).

•

Your full address.

•

Your telephone number and

area code.

Installation

When installing the hood, the

minimum distances from the

cooktop must be respected,

and the numerical sequence

and additional instructions

must be followed exactly as

indicated on the Installation

sheet.

External Exhaust Mode

(

- see also installation

sheet)

Cooking fumes and vapours are

conveyed outside through a

duct connected to the hood by

means of a collar.

The outlet duct diameter

must be the same as that of

the collar.

If a flue-damper is to be

installed, check that it can

open and close freely when

installation of the exhaust

duct is complete.

The hood can be supplied

with one (upper) or two

(upper and rear) exhaust

outlet holes.

The hood is usually set up

for using the upper exhaust

outlet.

The collar must be seated in

the upper exhaust outlet.

Use the rear exhaust outlet

(where present).

Where fitted, remove the

cover closing off the rear

outlet and collar.

Some models are fitted with

a plastic deflector that

closes off the rear outlet. If

fitted, remove it.

Fit the collar in the rear

outlet.

Put the cover (if fitted) in

the upper outlet.

Warning!

If the hood has a

carbon filter, this should be

removed.

Check that the switch inside the

hood (if fitted) is in

position“A” Extractor; if not,

set it to this position.

Air Circulation Mode

(

- see also installation

sheet)

The air is filtered by a carbon

filter and recycled into the

surrounding atmosphere. The

filtered air is released towards

the kitchen ceiling.

Warning!

If the hood does

not have a carbon filter,

order one and fit it before

use.

Check that the switch inside the

hood (if fitted) is in position

“F” Filter

; if not, set it to this

position.

If the plug is provided, close off

the upper exhaust hole.

Electrical connection

Before connecting the hood,

make sure the voltage

indicated on the rating plate

corresponds to the voltage in

your home.

The plate is located inside

the hood behind the grille.

For GB this appliance is

supplied without a plug and is

intended for direct connection

to fixed wiring in accordance

with national wiring

regulations. An all-pole

disconnection switch with a

minimum contact separation

of 3 mm must be included in

the fixed wiring in an easily

accessible position.

The Manufacturer shall not

be liable for any damage or

problem arising from the

failure to comply with the

above-mentioned

instructions.

4Gb33005.fm5 Page 11 Friday, August 24, 2001 9:51 AM
