CHANGE MODE TO SCREEN 2-4 BY PUSHING COMPUTER FORWARD IN BRACKET TO ACCESS:

CURRENT SPEED • Miles or Kilometers per hour • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph

RIDE TIME, "RTM" • Up to 9:59:59 • Increments of 1 second

RIDE DISTANCE, "DST" • Up to 999.99 M or K • Increments of 0.01 M or K

ODOMETER, "ODO" • Up to 999.99 M or K • Increments of 0.01 M or K

(ODO= Cumulative distance for BIKE 1 and BIKE 2)

1. Parts List

MOUNTING BRACKET

LINE : LCD Specification : Line 1, 2 and 3 modes do not change

1

2

3

4

1

2

3

4

SCREEN:

4

MOUNTING SENSOR

1

MOUNTING MAGNET (Front Wheel)

2

3

2. Mounting Instructions

3. Functions & Specifications

OR

OR

OR

AVERAGE SPEED, "AVS" • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph

MAXIMUM SPEED, "MAX" • 0-99.9 mph/Kph • Increments of 0.1 mph/Kph

TEMPERATURE • -19˚ to 120˚F/ -19˚ to 50˚C

CLOCK • 12 Hr format • Indicated by flashing colon ":"

BIKE ODOMETER, "BIKE ODO" • Up to 99,999 M or K • Increments of 0.1 M or K

This is the distance for the wheel size currently being used, it only appears when distance is registered

on both BIKE 1 and BIKE 2.

PUSH AND RELEASE FOR

MODE

CHANGE

CAUTION:

HOLD FOR

LESS THAN ONE SECOND

OR YOU WILL RESET ALL

OF THE RIDE DATA

SEE TOP OF

NEXT PAGE.

Thank you for purchasing the Planet Bike Protegé 9.0

Wireless bicycle computer. Planet Bike will donate 25% of

our profits from this purchase and any other Planet Bike

products you buy to grassroots bicycle advocacy groups

that work to improve conditions for cyclists. Enjoy your

new Protegé bicycle

computer and thank

you for making a

difference!

COMPUTER HEAD REMOVAL

5

Front

of bike

Rear

of bike

STEP 1: Thread the quick ties through the slots in the wheel sensor and attach to the

right or left fork arm so that it is on the same side as the mounting bracket, making sure

that the battery cover is facing the wheel (diagram #1).

STEP 2: Attach magnet to spoke using a screwdriver (diagram #2) so that the magnet

lines up with the top or bottom glossy line on the wheel sensor. Do not over-tighten

magnet screw.

STEP 3: Unthread sensor knob until sensor can swivel freely and rotate the sensor until

it is within 2mm of the magnet (diagram 3). Tighten the knob to fix sensor position.

STEP 4: Attach the computer bracket to the handlebars near the stem (diagram #4).

For 31.8 handlebars, no rubber shim is needed. For smaller diameter handlebars, use the

large shim to achieve a snug fit. Tighten the screw so the bracket will not rotate on the

handlebars. Slide the computer head into the bracket until it "snaps" into place.

STEP 5: Test for proper alignment of the magnet and sensor. First, push the computer

towards the front of the bike to activate. Now, spin the front wheel. Speed will begin to

register if the magnet and sensor are properly aligned.

TO REMOVE COMPUTER FROM BRACKET: Push the computer in the opposite

direction of when you snapped it into the bracket (diagram 5). The computer head will

“snap” out. Note that you may need to push hard. Don’t be afraid of breaking anything,

the computer will pop out.

W I R E L E S S

1. 31.8 mm Mounting Bracket 3. Computer Case

2. Wheel Sensor

5. Wheel Magnet

7. Quick Ties6. Rubber Shims

Line up Sensor

and Magnet at

same level

* Less than

2 mm apart

* DO NOT line

up Magnet

between

GLOSSY LINES

on Sensor.

TURN KNOB

COUNTER

CLOCKWISE

TO ADJUST ANGLE

ODO

AVS

MAX

BIKE

BIKE

BIKE

4. Battery
