Manual Logik L15SMW12 Steam Cleaner

Need a manual for your Logik L15SMW12 Steam Cleaner? Below you can view and download the PDF manual for free in English. This product currently has 4 frequently asked questions, 0 comments and has 0 votes. If this is not the manual you want, please contact us.

Is your product defective and the manual offers no solution? Go to a Repair Café for free repair services.

Manual

Thank you for purchasing your new Logik Steam Mop.

We recommend that you spend some time reading this instruction

manual in order to fully understand all the operational features it offers.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

GB-5

Visit Partmaster.co.uk today for the easiest way to buy

electrical spares and accessories. With over 1 million

spares and accessories available we can deliver direct

to your door the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK

customers only) Calls charged at National Rate.

This symbol on the product or in the instructions means that your

electrical and electronic equipment should be disposed at the end of its

life separately from your household waste. There are separate collection

systems for recycling in the EU. For more information, please contact the

local authority or your retailer where you purchased the product.

QSG-L15SMW12-130719V2

SPECIFICATIONS

Model No: L15SMW12

IPX4, Class 1

Voltage: 220-240V~ 50Hz 1500W

Water Capacity: 9.6 US . oz (300 ml)

We continually strive to improve our products. Speciﬁcations may change without

prior notice.

GETTING STARTED (Cont)

Instruction Manual

Steam Mop

L15SMW12

If you live in a hard water area, it is advisable

to use distilled or de-mineralised water.

Avoid using water containing softeners,

perfumes or additives.

Fill the Water Tank

1. Make sure the steam mop is unplugged from the

mains socket and the pump ON/OFF Switch is at “ ”

position.

2. Turn the cap anti-clockwise to open the water tank.

Fill it carefully with fresh water by using the supplied

funnel and filler cup.

Do not fill the unit above the MAX mark indicated on

the steam mop.

3. Turn the cap clockwise to close the water tank.

The micro-bre cleaning pads have a coloured

tab so that a dierenct pad can be asigned to

dierent tasks or rooms in the house.

Attach Mop Pad

Place the micro-fibre cleaning pad underneath the mop

head. Frap the rope with tight button.

When using the steam mop on carpets, place the mop

head with micro-fibre cleaning pad in place over the

carpet glider.

Micro-ber Cleaning Pad

Green

Red

Water tank full

Add water to water tank

Power & Water Level Indicator Description

3. Press the ON / OFF switch to the “ ” position. Steam will damper the micro-fibre

pad. It’s normal that for pump to make a noise and shake when beginning. To

stop releasing steam, press the ON / OFF switch to the “ ” position.

4. Slowly pass over the surface to be cleaned. To sanitize an area of your oor, leave

the steam mop over that area for a few seconds.

1. Sweep or vacuum the oor prior to use.

2. Connect the mains cable to the mains socket. The steam mop will start up and the

power indicator will light up red.

 

attached to the mop head or without water in the water tank.

 

ON/OFF switch must be turned o.

It may take several seconds for the steam mop to heat up and the steam

to be ready.

During operation, do not touch the micro-bre cleaning pad and steam

mop head as they get very hot.

BASIC OPERATION

5. When the steam mop stops emitting steam, the water tank is empty. The pump

will gurgle and shake. Press the ON/OFF switch to the “ ” position immediately.

Unplug the steam mop from the mains socket, rell the water tank, turn on the

mop again and continue cleaning.

6. When nished using the steam mop, unplug the mains cable from the mains

socket. Carefully remove the micro-bre cleaning pad from mop head as the

micro-bre cleaning pad and mop head will be hot.

MAINTENANCE

 

 

detergent. Never use bleach or fabric softener when washing the reusable

micro-bre cleaning pad.

 

can be dried in a dryer on a low heat setting.

 

nished using the steam mop. Upright storage of the steam mop with a wet

micro-bre cleaning pad may result in the formation of white marks on your

oor. To remove the white marks, clean the area with vinegar.

 

cleaning pad is required to ensure long life and continued cleaning ability.

 Before tting a new micro-bre cleaning pad, wash and dry it rst.

 To wash the micro-ber cleaning pad, simply put it in your washing machine and

use the warm water setting. We recommend washing your micro-bre cleaning

pads separately to other fabrics or placing them in a garment bag.

 

so that they will last much longer.

 As you use the micro-bre cleaning pad, you will notice that sometimes a thread

will loosen or pull out. This is normal and you should never pull at the loose

thread! Pulling the thread can cause the weave to come undone. Instead, simply

trim the thread with a pair of sharp scissors.

GB-4

DSG Retail Ltd. (co. no. 504877)

Maylands Avenue, Hemel Hempstead, Herts., HP2 7TG, UK.

L15SMW12_IB_130719_Shaun.pdf 1 19/07/2013 4:03 PM

Rating

Let us know what you think about the Logik L15SMW12 Steam Cleaner by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.

Are you satisfied with the Logik L15SMW12 Steam Cleaner?
Yes No

Be the first to rate this product

0 votes

Join the conversation about this product

Here you can share what you think about the Logik L15SMW12 Steam Cleaner. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.

More about this manual

We understand that it’s nice to have a paper manual for your Logik L15SMW12 Steam Cleaner. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Logik. They might be able to provide an original manual. Are you looking for the manual of your Logik L15SMW12 Steam Cleaner in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.

Specifications

Brand	Logik
Model	L15SMW12
Category	Steam Cleaners
File type	PDF
File size	0.63 MB

All manuals for Logik Steam Cleaners
More manuals of Steam Cleaners

Frequently Asked Questions about Logik L15SMW12 Steam Cleaner

Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.

Can I use a steam cleaner on wooden floors like laminate? Verified

Yes, but wooden floors are more vulnerable than for example tiles. Use the lowest setting on the steam cleaner and use a cloth to prevent damage.

This was helpful (343) Read more

My steam cleaner is generating very little steam, what can I do? Verified

First check the water container to see if there is enough water. Another reason for decreased steam output can be scale buildup. Consult the manual of your specific steam cleaner to learn how to descale your model.

This was helpful (13) Read more

I can’t press the steam button/lever, why is that? Verified

Some steam cleaners have a child safety lock. If this is activated, the steam button or lever will not work. Deactivate the child safety lock to use the steam cleaner.

This was helpful (10) Read more
