Manual

MP3 OPERATION

P.2 P.3

TRACK SEARCH

Press “AMS” button more than 2 seconds, “TRK SCH” will be shown on the display and “TRK 0” will

appear on the display for you to enter. Rotate the volume button to shift number 0-9 in loop. Then,

press it shortly for the first digit selected. Repeat the same procedure for the rest of the digits if

require. Once all digits are entered, press the volume button more than 2 seconds to start playing

the selected track.

increase setting level and vise versa.

c)Press this button more than 2 seconds, it activates the selection mode in cyclical position.

Remark : “MULT OFF/ MULT ON” and “BEEP ON/ BEEP OFF” are not available for this model.

15/16. MANUAL UP/DOWN TUNING / TRACK SEEK UP/DOWN

On radio mode, pressing this button more than 2 seconds, it will tune one frequency step higher or lower. On

CD/USB/SD mode, pressing this button shortly will move to the one track higher or lower. Pressing more than

2 seconds, it will move fast forward or backward to a specific position.

17. STATION PRESET BUTTON (1-6)

a)Each station preset can be store in FM1, FM2, FM3, MW1 and MW2. Press the button shortly recalls the

station frequency which was memorized.

b)It can be memorized the frequency stations manually on specific preset stations by holding the desired

specific preset station in 2 seconds.

c) Press the preset 2 to scan the first 10 seconds of all the tracks during CD/USB/SD mode.

d) Press the preset 4 to play the tracks in random order during CD/USB/SD mode.

e) Press the preset 5/6 to search -10/+10 track during USB/SD mode.

18. RESET

The reset button is located on the front of main panel. This reset circuitry is provided to protect the unit's

microprocessor. Whenever the reset button is activated, all preset memories content will be erased. It

should only be activated under the below conditions: a) Initial installation after all wires are completed.

b) Abnormal operation.

19. AUXILIARY INPUT

Press MODE button (10) until the “AUX” mode is shown on display. The unit is ready to play files from the

external audio device.

20. SD CARD SLOT

Press MODE button (10) until the “MEM-CARD” mode is shown on display. The unit is ready to play files

from the SD card.

21. USB HOST

Press MODE button (10) until the “USB-DRIV” mode is shown on display. The unit is ready to play files

from the USB device.

FILE SEARCH

Press “AMS” button more than 2 seconds and press one more, the “FILE SCH” will be shown on the

display. Press “AMS” button and rotate the volume button to find the desired directory. Press the

volume button to enter the desired directory. Rotate the volume button to select the file. Then, press

the volume button more than 2 seconds to start playing.

CHARACTER SEARCH

Press “AMS” button more than 2 seconds and press twice, the “CHAR SCH” will be shown on the

display for you to enter. Rotate the volume button to shift “A-Z”, “0-9” & * (space) in loop. Then, press

it shortly for the first character selected. Repeat the same procedure for the rest of the character if

require. Once the whole name is entered, press the volume button more than 2 seconds to start

playing.

Remark :

a) The media must contain files name in order to use in searching.

b) If only partial letters are entered for searching, you might not get it correctly.

c) If the above search can not be completed within 10 seconds, the unit will continue play back the

current file.

d) Do not attempt to play a media containing non-MP3 files. Otherwise, the radio may not work properly.

WIRE CONNECTION

ISO CONNECTOR

FROM CABLE SIDE

FOR 4 SPEAKERS

RIGHT REAR + RIGHT REAR

RIGHT FRONT + RIGHT FRONT

LEFT FRONT + LEFT FRONT

LEFT REAR + LEFT REAR

(GRAY) (GRAY/BLACK)

(PURPLE)

(PURPLE/BLACK)

(GREEN)

(GREEN/BLACK)

(WHITE) (WHITE/BLACK)

MEMORY

GROUND

IGNITION

(YELLOW)

(BLACK)

(RED)

POWER

ANTENNA

(BLUE)

POWER

FROM CABLE SIDE

ISO CONNECTOR

FUSE 10A

ANTENNA

RCA LINE OUT

INSTALLATION

METAL

MOUNTING

STRIP

DASHBOARD

MOUNTING

CASE

CONSOLE

HEXAGON

NUT

HEXAGON

BOLT

UNIT REMOVAL

1. Remove Front Panel and

Frame.

2. Insert the removal keys

into the slot and gently to

remove mounting case.

3. Keep removal keys in a

safe place for future

removal of unit.

REMOVAL KEYS

END OF LIFE DISPOSAL

Electric and electronic equipment contains materials, components and substances that can be hazardous to

your health and the environment, if the waste material (discarded electric and electronic equipment) is not

handled correctly. Electric and electronic equipment is marked with the crossed out trash can symbol, seen left.

This symbol signifies that electric and electronic equipment should not be disposed of with other household

waste, but should be disposed of separately. All cities have established collection points, where electric and

electronic equipment can either be submitted free of charge at recycling stations and other collection sites, or

be collected from the households. Additional information is available at the technical department of your city.

FUNCIONAMENTO EM GERAL

1. LIGAR/DESLIGAR

Premir o botão para “LIGAR” ou “DESLIGAR” a alimentação.

2. SELECTOR DE BANDA / PAUSA

a) De cada vez que premir este botão, a banda de rádio é alterada.

b) Premir este botão para parar a faixa durante a reprodução.

3. BOTÃO GRAVAÇÃO AUTOMÁTICA/PRÉ-BUSCA / REPETIR

a) Premir este botão mais do que 2 segundos, busca todas as frequências acima e memoriza

automaticamente até 6 estações pré-definidas pela captura da frequência. Premir este botão ligeiramente

rechama as frequências de estação memorizadas (1-6) automaticamente a cada 5 segundos.

b) Premir este botão para repetir a faixa durante a reprodução.

4. ENTRADA DISCO

5. VISOR DIGITAL LCD

6. BOTÃO VISOR

Premir este botão serve para mostrar informação disponível.

Português

8. EJECTAR

Premir o botão para ejectar o disco da entrada do disco.

9. SOLTAR O PAINEL

Este botão é usado para soltar o painel da unidade.

10. MODO / SILÊNCIO

a) Premir brevemente para seleccionar Rádio (SINTONIZADOR), CD (S-CDP), USB (UNID-USB), SD

(CARTÃO MEM) ou AUX (AUX).

b) Premir este botão mais do que 2 segundos para cortar o som.

11. RDS (RADIO DATA SYSTEM)

Pode aproveitar as vantagens RDS no rádio FM como se segue:

Nome do Programa de Serviço (PS): Quando a estação RDS é recebida, o nome da estação aparecerá no visor.

Programa de Tráfego (TP): Quando a estação com programa de tráfego é recebida, o indicador “TP” aparecerá

no visor.

Frequências Alternativas (AF): A unidade continuará a verificar o sinal de frequências alternativas de tempos a

tempos. Se a nova frequência alternativa for mais forte que a actual, mudará automaticamente para a nova

frequência. Premir este botão ligeiramente, o estado do modo de comutação AF aparecerá no visor, como se

segue:

a) RDS está ligado: AF está ligado e o sinal RDS é recebido.

b) RDS está desligado: AF está desligado.

c) RDS está a piscar: AF está a buscar mas o sinal RDS não é recebido.

Outras Redes Melhoradas (EON): Quando sintonizar uma estação que está ligada a outras por EON, o rádio

está capaz de receber Avisos de Tráfego das estações ligadas.

12. TA ( )AVISOS DE TRÁFEGO

Premir este botão para seleccionar o modo TA. Quando o modo TA está ligado, está apto a receber avisos

CONFIGURAR A HORA DO RELÓGIO MANUALMENTE

a) Premir o botão e manter premido até que o visor pisque e largar.

b) Rodar botão “VOL/SEL” no sentido horário para definir HORA e anti-horário para definir MINUTOS.

7. BUSCA

Premir este botão para buscar as estações FM / MW recepcionáveis. Quando as estações recepcionáveis

estão sintonizadas, são monitorizadas por 5 segundos aproximadamente antes de avançar para a próxima

recepcionável. Premir de novo o botão para parar a busca.

WARNING!!

Remove two small screws on the

top of the unit before operate the

unit. Otherwise, it may not work

properly.
