Contents Page
ʋ Preparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋ Setting the programmes . . . . . . . . . . . . . 2
ʋ Drying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋ Notes on laundry . . . . . . . . . . . . . . . . . . 5
ʋ Button signals . . . . . . . . . . . . . . . . . . . . . 5
ʋ Fine adjustment of the drying result . . . . 6
ʋ Important Information . . . . . . . . . . . . . . . 6
ʋ Overview of programmes . . . . . . . . . . . . 7
ʋ Installation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋ Frost protection / Transport. . . . . . . . . . . 8
ʋ Care and cleaning . . . . . . . . . . . . . . . . . . 9
ʋ Technical data . . . . . . . . . . . . . . . . . . . 10
ʋ Optional accessories . . . . . . . . . . . . . . . 10
ʋ Normal noises . . . . . . . . . . . . . . . . . . . .11
ʋ What to do if ... / After-sales service . . . 12
ʋ Safety instructions . . . . . . . . . . . . . . . . 13
Select On/Off for buzzer at the end of the programme. ˎ & Buzzer
Reduced temperature for delicate fabrics ' that require a longer
drying time; e.g. polyacrylics, polyamide, elastane, acetate silk.
ˎ & Low heat
Reduces creasing and prolongs the 'reduced ironing' phase after
the programme has finished.
ˎ Reduced
ironing
... and adapt to individual requirements
Never start the dryer if it is damaged.
Inform your after-sales service.
Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
See also separate instructions for “basket for woollens”
(depending on the model)
Your new dryer
Intended use
Preparation
Installation a page 8
Selecting and adjusting the programme
Additional functions
Select the drying programme ...
Press the Start/StopÒĔ button
Make sure your hands are dry.
Hold the plug only.
Connecting the
mains plug
Display
status/
service
Programme selector
All buttons are sensitive and only
need to be touched lightly.
ʋ For domestic use only.
ʋ Only to be used for drying fabrics that have been
washed with water.
.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be operated by children 8 years old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or knowledge if they are
supervised or have been instructed in its use by
a responsible adult.
3
2
1
Drying
Drying
Condensate container with filter
Control panel
Air inlet
Two-part
fluff filter
Drum
End of programme as soon as the AntiCrease/End indicator lamp lights up.
Interrupt programme Adding or removing laundry.
The drying operation can be interrupted briefly to add or remove laundry. However, it must then be
continued until it has finished.
1. Open the door. The drying process is interrupted.
2. Add or remove laundry then close the door.
3. If required, select a new programme and additional functions.
4. Press the ĔStart/Stop button. The remaining time is updated after a few minutes.
Display/
Remaining
time
h:min End of programme after 1-24 hours (button may need to be pressed several times) can always be set
to the nearest full hour.
Cln Automatic cleaning of the heat exchanger.
Fine adjustment
of the drying
result
The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3) for the L Cottons,
# Easy-Care, 1 Mixed Load and A Super Quick 40’ programmes apresetting = 0. After one of
these programmes has been finely adjusted, the setting is retained for the others.
Further information apage 6.
0, 1, 2, 3
Only use the dryer with the fluff filter
inserted.
Emptying condensation
Empty the container after each drying cycle, not during drying.
1. Remove the condensate container and hold it level.
2. Pour out the condensation.
3. Always push container in fully until it clicks into place.
If the Container indicator lamp flashes despite the container having been
emptied a Filter in condensate container, page 9.
Cleaning the fluff filter
The fluff filter consists of two parts. Clean the inner
and outer filter after every drying cycle:
1. Open the door. Remove fluff from the door/door area.
2. Pull out both parts of the fluff filter.
3. Remove fluff from the edge of the shaft. Fluff should not fall
into the open shaft.
4. Open the filter and remove all the fluff.
5. Rinse both parts under running water and dry thoroughly.
6. Close the inner and outer filter, put them back together
and reinsert them into the appliance.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer is equipped with an automatic reduced ironing function. The drum is moved at specific time
intervals for 60 minutes once the programme has ended. The laundry stays loose and fluffy (or
120 minutes if the additional Reduced ironing function is selected).
Congratulations - you have chosen to buy a modern, high-quality Bosch
domestic appliance.
The condensation dryer with heat exchanger and automatic cleaning
function is outstanding in terms of efficient energy consumption and low
maintenance requirements a page 6.
Every dryer which leaves our factory is carefully checked to ensure that
it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased to
help.
Environmentally-responsible disposal
Dispose of packaging in an environmentally-responsible manner.
This appliance is designated according to European directive
2002/96/EC which governs waste electrical and electronic
equipment - WEEE).
The directive provides an EU-wide framework for the return and recycling
of used appliances.
For further information about our products, accessories, spare parts and
services, please visit: www.bosch-home.com
Do not pull out/empty the
condensate container when drying is in progress.
Drum interior light
(depending on the
model)
Important Information
Your dryer is designed to be particularly energy efficient. Its technical features include a
refrigeration circuit, which uses energy efficiently in a similar way to a refrigerator.
The dryer's heat exchanger is cleaned automatically during drying.
The fluff filters and filter in the condensate container must be cleaned regularly.
Never operate the dryer without the fluff filters and without filter in condensate container.
ʑ
Fluff filters
During drying, fluff and hair from the laundry is trapped by the fluff filter. Blocked fluff filters
may impair the heat exchange process.
The fluff filters must therefore be cleaned after every drying cycle. Rinse regularly under
running water a page 4.
ʑ
Filter in the condensate container
The filter in the condensate container cleans the condensation. This condensation is required
for the automatic cleaning process. The filter should be cleaned regularly under running
water. Empty the condensate container before cleaning the filter a page 4/9.
ʑ
Fabrics
Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:
e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent. etc.
Empty all pockets.
Do not dry non-breathable fabrics.
Avoid drying items that produce a lot of fluff.
Woollens should be refreshed only, using the woollens programme.
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(cDry at normal temperature.
'cDry at low temperature a in addition, select &üLow heat.
)cDo not machine dry.
Always observe the safety instructions on page 13.
Do not tumble-dry the following fabrics, for example:
– Non-breathable fabrics (e.g. rubber-coated).
– Delicate materials (silk, curtains made from synthetic material) a these may crease.
– Oil-stained laundry.
Drying tips
– To ensure an even result, sort the laundry by fabric type and drying programme.
– Always dry very small fabrics (e.g. baby socks) together with
large items of laundry (e.g. towels).
– Close zips, hooks and eyelets, and button up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry a Risk of creasing.
Allow laundry to finish drying in the air.
– Do not dry woollens in the dryer. They may, however, be refreshed
a page 7 Wool finish programme.
– Do not iron laundry immediately after drying; fold items up and leave for a while a residual
moisture will then be distributed evenly.
– The drying result depends on the type of water used during washing. aFine adjustment of
the drying result a page 6.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.
aDo not use the Very Dry programme.
– The drying of starched laundry should be limited. a Starch leaves behind a coating that
impairs drying.
– When washing laundry that is to be tumble-dried afterwards, use the correct amount of fabric
softener as specified in the manufacturer's instructions.
– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the Timed
programme. Also suitable for subsequent drying.
Environmental protection/energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine a the higher the spin
speed, the shorter the drying time will be, thus less energy is consumed. Also spin easy-care
laundry.
– Use the maximum recommended capacity, but do not exceed it
a Programme overview page 7.
– Make sure the room is well ventilated during drying.
– Do not cover or seal the air inlet.
Button signals
Setting the volume for button signals
Selectable values: 0 (off), 1 (quiet), 2 (normal), 3 (loud).
1 x to the
right
Press and hold
&üLow heat
and turn 2 x to the right
Press
ĔStart/Stop until the
required volume is reached
Turn to
Off
Turn to
Off
Container Empty the condensate container.
Clean the filter in the condensate container if necessary a page 9.
Filter Rinse the fluff filters under running water a page 4.
Observe the safety instructions on page 13.
Read these instructions and the separate
Energy-saving mode instructions before switching
on the dryer.
4
Clean fluff filters reduce energy consumption.
Fine adjustment of the drying result
Adjustment of the levels of dryness
1 x to
the right
Press and hold
&
üLow heat
and turn 5 x to the right
Press
&
üLow heat until
the required level is reached
Turn to Off
Turn to Off
L:00, L:01, L:02, L:03 are shown in sequence
Short signal when changing from L:03 to L:00, otherwise long
signal.
7
Programme overview see also page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.
After drying...
ciron laundry lightly iron laundry @cdo not iron laundry cmangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION
**L Cottons
max. 7 kg
Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.
**# Easy-Care
max. 3.5 kg
Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.
**1 Mixed Load
max. 3 kg
Mixed items of laundry madeof cotton and synthetics (Mix).
*Iron Dry
c÷@c
Fabrics suitable for ironing (iron fabrics in order to avoid creasing).
Cupboard Dry
@
Single-layer fabrics.
*Cupboard Dry Plus /
Very Dry
@
Fabrics made of thick, multilayered items of clothing.
Wool finish
max. 3 kg
Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.
Remove fabrics once the programme has ended and allow to dry.
A Super Quick 40’
max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may
differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric
and loading capacity.
Z Sportswear
max. 1.5 kg
Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with
removable internal lining separately).
Timed Programme
warm 30’
max. 3 kg
Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying.
*for L Cottons and # Easy-Care programmes only
**Dryness levels can be selected individually a Cupboard Dry Plus, Cupboard Dry and Iron Dry (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing.
Recommendation: Dry separately.
9308/ 9000907650
*907650*
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 Munich, Germany
WTW863S1GB
Loading…
Rating
Let us know what you think about the Bosch WTW863S1GB Dryer by leaving a product rating. Want to share your experiences with this product or ask a question? Please leave a comment at the bottom of the page.More about this manual
We understand that it’s nice to have a paper manual for your Bosch WTW863S1GB Dryer. You can always download the manual from our website and print it yourself. If you would like to have an original manual, we recommend you contact Bosch. They might be able to provide an original manual. Are you looking for the manual of your Bosch WTW863S1GB Dryer in a different language? Choose your preferred language on our homepage and search for the model number to see if we have it available.
Specifications
| Brand | Bosch |
| Model | WTW863S1GB |
| Category | Dryers |
| File type | |
| File size | 4.99 MB |
All manuals for Bosch Dryers
More manuals of Dryers
Frequently Asked Questions about Bosch WTW863S1GB Dryer
Our support team searches for useful product information and answers to frequently asked questions. If you find an inaccuracy in our frequently asked questions, please let us know by using our contact form.
Why is de drum of my dryer larger than that of my washing machine, even though they have the same capacity? Verified
To properly dry laundry, a dryer needs to have air. This needs space and that's why the drum needs to be larger.
This was helpful (2993) Read moreWhat is the difference between a condenser dryer and a vented dryer? Verified
In a condenser dryer the condensed water vapour is drained and collected in an internal reservoir. In a vented dryer the hot, moist air is drained through a hose, for example out of a window. A vented dryer is cheaper to use than a condenser dryer
This was helpful (857) Read moreCan I stack my dryer and washing machine? Verified
In general it is possible to directly stack a dryer and washing machine directly on top of each other. This only works with front loading models. However, it is advisable to use a fitting accessory to do so. This will prevent the machines from vibrating and falling off and also prevents damage to the bottom machine.
This was helpful (689) Read moreCan I connect a dryer to an extension cord? Verified
Appliances that require large amounts of power, like a dryer, can not be connected to all extension cords. See what the power usage of the dryer is, which is indicated in Watt, and check if the extension cord can handle this. There are extension cords with thicker cables that are made to handle larger appliances.
This was helpful (534) Read moreWhat is the difference in usage between a washer-dryer and a separate washing machine and dryer? Verified
The biggest advantage of a washer-dryer is that it takes less space. However, a separate dryer will be able to dry more than a washer-dryer. A washer-dryer also uses relatively more energy and requires more time.
This was helpful (523) Read more
Join the conversation about this product
Here you can share what you think about the Bosch WTW863S1GB Dryer. If you have a question, first carefully read the manual. Requesting a manual can be done by using our contact form.
